Home > Electrical & Electronics > Telecommunication & Broadcasting > Set Top Box > Factory Wholesale Support Wifi Biss Powervu Cccam Scrambled Channels Dvbs2 Dvbt2 hd Digital Fta Combo Decoder
Factory Wholesale Support Wifi Biss Powervu Cccam Scrambled Channels Dvbs2 Dvbt2 hd Digital Fta Combo Decoder
US$ 1 - 17
MOQ: 1000 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
OEM
Model Number:
t2+s2 8901
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Vmade 8901 HIGH PERFORMANCE T2 S2 FREE TO AIR TV BOXUS$ 1 - 14MOQ: 1000 Pieces -
Vmade 8901 T2 S2 FREE TO AIR TV BOX WITH 32X16Mbit DDR2US$ 1 - 14MOQ: 1000 Pieces
-
HD 1080P DVB T2 S2 Combo Digital Decoder Wifi Auto Roll Powervu Cccam rf Rs232US$ 1 - 15MOQ: 1000 Pieces
-
Manufacturer Direct Most Hot Sale DVB T2 S2 Digital Combo Receiver Auto Roll Powervu Cccam BissUS$ 1 - 15MOQ: 1000 Pieces
-
Factory Wholesale HD DVBT2+S2 Combo Decoder 1080p Autoroll Powervu Biss Iks CccamUS$ 1 - 15MOQ: 1000 Pieces
Place of Origin
Guangdong, China
Brand Name
OEM
Model Number
t2+s2 8901
European standard High Definition DVB-T2 S2 Combo Digital Receiver
Why Choose DongzhouJun Tech.Company?
- 12-year professional manufacture experience
- Perfect quality,from sales record in the nearest 3 years, no repair
- Focus on OEM, Moq of OEM is 1000pcs,customize hardware,software and package
- Fast delivery.1-5 work days for samples, 7-20 work days for bulk orders.
| Model | DVB-T2+S2 COMBO | |||
| Hardware | ||||
| CPU | Montage CT6001 | |||
| Memory | 1GB DDRIII | |||
| Flash | 8M bytes | |||
| Demodulator Type | Montage DM6000 Chip Set | |||
| S2+TUNER | Montage TS2022 Chip Set | |||
| T2+TUNER | MaxLinear MXL 608 | |||
| Front Panel | USB 2.0 Embedded One Host, | |||
| 4-digit LED display on front panel | ||||
| red LED Standby,green LED Lock | ||||
| Panel KEY, POWER, CH+ ,CH- | ||||
| Rear Panel | S2 LNB IN input connector | IEC60169-2 | ||
| T2 ANT input connector | IEC-162-2(IEC Female) | |||
| HDMI V1.3 | ||||
| RCA CVBS AL AR Connector x1 | ||||
| Ypbpr RCAx1 | ||||
| Coaxial x1 | ||||
| Power AC100~240V 50Hz/60Hz | ||||
| DVB-T2 Demodulation | ||||
| DVB-T2 Demodulation | Terrisal Receiver StandardDVB-T2/T(EN_302755 V1.3.1/EN 300744) | |||
| Input RF Frequency 48~866MHZ | ||||
| Bandwidth6MHz,7MHz,8MHz | ||||
| Constellation QPSK 16-QAM 64-QAM and 256-QAM | ||||
| FEC 1/2, 3/5,2/3, 3/4,4/5,5/6 | ||||
| Guard Interval1/128 1/32 1/16 19/256 1/8 19/128 1/4 | ||||
| FFT Mode 2K/ 8K/32K | ||||
| Support Single and multiple PLPS | ||||
| Input level -83~ -5dBm | ||||
| DVB-S2 Channel Decoder | ||||
| DVB-S2 Channel Decoder | Frequency Range | 950MHz-2150MHz | ||
| Sensitivity Level | - 10~ - 81dBm | |||
| Mode IFFT | 2k,8k | |||
| FEC Mode | 1/4, 1/3, 2/5, 1/2, 3/5, 2/3, 3/4, 4/5, 5/6, 8/9, 9/10 | |||
| Guard intervals | 1/4,1/8,1/16,1/32 | |||
| Constellation | QPSK,8PSK,16APSK | |||
| Neighboring channels immunity and Protection |
According to ETSI TR 101 190 V1.2.1 | |||
| Active Ant Power | 13/18V DC @ 500mA MAX,Overload Protection | |||
| Sortware Features | ||||
| •Fully comply with DVB-T/T2 and H.264, MPEG-4, MPEG-2 Standard | ||||
| •Fully comply with DVB-S/S2, MPEG-2/4 H.264 Standard | ||||
| •Support BISS KEY | ||||
| •Supports single / multiple or blind search satellite search | ||||
| •DiSEqC 1.0 / 1.1 / 1.2 | ||||
| •The maximum speed of the traffic flow of at least 50 Mbit / sec | ||||
| •Support 3D interface | ||||
| •Sleep Timer | ||||
| •Support teletext/subtitle/muti-language | ||||
| •Powerful and highly effective 7-day EPG function | ||||
| •AUTO, 16:9 Pillar Box, 16:9 Pan G Scan, 4:3 Letter Box, 4:3 Pan G Scan, 4:3 Full, 16:9 Wide Screen | ||||
| •USB 2.0 for PVR,TIMESHIFT,software upgrade and media files playback | ||||
| •Video output resolution: 480i/576i/480p/576p/720p/1080i/1080P | ||||
| Decoder | ||||
| Video Decoder | Compliant with: MPEG-4 part10/MPEG-2 ISO/IEC 13818 MPEG-4 Simple/Main/Advanced Profile@LEVEL3(10Mbps) MPEG-2 Main Profile# Main Level(15Mbps) H.264 MP#L3(10Mbps).H.264 HP L4.1(25Mbps) |
|||
| Audio Decoder | MPEG-1, MPEG-2 (Layer I/II), MP3, AC-3 (Dolby Digital), AAC-LC, WMA E-AC-3 (Dolby Digital Plus) decoding HE-AAC 5.1 multi-chhannel decoding |
|||
| Powerful Multimedia Features | ||||
| MediaCodec | avi. mpg, .dat, .vob, .div, .mov, .mkv, .jpeg, .ts etc | |||
| Audio Codec | WMA,MP3,AAC (.wma,.mp3,m4a) |
|||
| Photo Codec | JPEG, BMP, PNG |
|||
| License | ||||
| Optional DTS, Dolby Digital, Dolby Digital Plus, RM/RMVB, Divx License. | ||||
| Accessories | ||||
| Accessories | gift box | |||
| AV cable optional | ||||
| HDMI cable optional | ||||
| IR remote control | ||||
| User Manual | ||||
| Loading | ||||
| Loading | machine size | 168*95*37mm | Packaged size | |
| machine weight | 0.7KG | Packaged weight | 0.8KG | |
| Loading for 20GP | 9200PCS | Loading for 40HQ | 21360PCS | |
Company Information
1. Established in 2003, we have over 13 years of experience both on design and manufacture.
2. Our products meeting CE, FCC, Rohs, ISO9001 standards.
3. Working on OEM/ODM project.
4. Good after-sale service , 1 year warranty.
5. We are supplier of Wal-Mart.
