Home > Electrical & Electronics > Telecommunication & Broadcasting > Set Top Box > Digital Biggest Hot Sales Atsc 8930 Digital tv Box High Quality Atsc Mepge4 H.24 Metal tv Encodr
Digital Biggest Hot Sales Atsc 8930 Digital tv Box High Quality Atsc Mepge4 H.24 Metal tv Encodr
US$ 12.5 - 15.1
MOQ: 1000 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
OEM/Vmade
Model Number:
ATSC-8930
Payment & Shipping
Payment Methods:
Port of Shipment:
FOB SHENZHEN
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
HD Digital Converter ATSC HD TV Receiver 1080P H.264 tv TerrestrialUS$ 1 - 10.8MOQ: 2000 Pieces -
2016 Factory Price HD ATSC Digital Video Broadcasting Terrestrial Receiver Dvb-t Atsc H.264 TV Set Top BoxUS$ 11.9 - 14.5MOQ: 1000 Pieces
-
Chian Lowest New HD PVR Digital ATSC TV Tuner Usb 1080P TV Box Receiver Mpeg4 Support USB for Mexico/USA/CanadaUS$ 11.9 - 14.5MOQ: 1000 Pieces
-
China Supplier Good Quality Digital tv Converter Set Top Box ATSC ReceiverUS$ 11.9 - 14.5MOQ: 1000 Pieces
-
New Encoder New HD PVR Digital ATSC TV Tuner Usb 1080P TV Box Receiver Mpeg4 Support USB for Mexico/USA/CanadaUS$ 11.9 - 14.5MOQ: 1000 Pieces
Place of Origin
Guangdong, China
Brand Name
OEM/Vmade
Model Number
ATSC-8930
| SPECIFICATION: | |||||||
| Features | 1. CPU:MSTAR-MSD7802(128 pin) MIPS 34Kf@600MHZ | ||||||
| 2. Memory: 32X16Mbit DDR2 Frequency1066 | |||||||
| 3.Flash: 32M bytes | |||||||
| 4.Demodulator Type: MSB1237 Chip Set | |||||||
| 5.TUNER:Rafael R836 | |||||||
| 6.USB 2.0:Embedded One Host, | |||||||
| 7.Front Panel:4-digit LED display on front panel ; RED LED Standby,GREEN LED Lock | |||||||
| Rear Panel | Tuner RF input connector | ||||||
| Tuner RF Loop through connector | |||||||
| HDMI V1.3 | |||||||
| AV RCA x1 | |||||||
| Ypbpr RCAx1 | |||||||
| Coaxial x1 | |||||||
| Power AC100~240V 50Hz/60Hz | |||||||
| Demodulation | Standard ISO/IEC 13818-1; ARIB STB-B10 | ||||||
| Input max. bit stream rate: 36Mbps (serial) / 9Mbps (parallel) | |||||||
| ATSC NTIA and 8VSB Standard | |||||||
| QPSK, 64QAM, 256QAM | |||||||
| FEC: 1/2, 2/3, 3/4, 4/5,5/6, | |||||||
| Guard Interval: 1/4,1/8,1/16,1/32,1/128 | |||||||
| FFT Mode: 2K, 8K, 32K | |||||||
| RF input frequency: 54-803MHz | |||||||
| Bandwith: 6MHz | |||||||
| Input level: -83 - -5dBm | |||||||
| Video Decoding | Compliant with: MPEG-4 part10/MPEG-2 ISO/IEC 13818 | ||||||
| MPEG-4 Simple/Main/Advanced Profile@LEVEL3(10Mbps) | |||||||
| MPEG-2 Main Profile# Main Level(15Mbps) | |||||||
| H.264 MP#L3(10Mbps).H.264 HP L4.1(25Mbps) | |||||||
| Audio Decoding | MPEG-1, MPEG-2 (Layer I/II), MP3, AC-3 (Dolby Digital), AAC-LC, WMA | ||||||
| E-AC-3 (Dolby Digital Plus) decoding HE-AAC 5.1 multi-chhannel decoding | |||||||
| MediaCode:avi. mpg, .dat, .vob, .div, .mov, .mkv, .jpeg, .ts etc | |||||||
| Sortware Features | USA ATSC 8VSB /64/256 QAM digital broadcast HD receiver | ||||||
| Converts digital broadcast to your analog TV | |||||||
| By remote control to choose the RF 3/4 ch output | |||||||
| Sleep Timer | |||||||
| Support teletext/subtitle/muti-language | |||||||
| Powerful and highly effective 7-day EPG function | |||||||
| AUTO, 16:9 Pillar Box, 16:9 Pan G Scan, 4:3 Letter Box, 4:3 Pan G Scan, 4:3 Full, 16:9 Wide Screen | |||||||
| USB 2.0 for PVR,TIMESHIFT,software upgrade and media files playback | |||||||
| Video output resolution: 480i/576i/480p/576p/720p/1080i/1080P | |||||||
| Remarks: | |||||||
| 1.The above price are ex-factory price, excluding tax, excluding freight | |||||||
| 2. Lead time : 15-20 working days | |||||||
| 3. Payment: TT 30% advance deposit, balance paid before shipment | |||||||
| 4. Warranty: One year for free technical service and repair | |||||||
