8ch Video Cloud Service Support Network Hd Dahua Dvr
Feature:
- HD iDVR Three in one: DVR / HVR / NVR features 3-in-1, multi-mode input, support four analog video encoding, support for high-definition video mixing analog inputs + network support pure HD network video input.
- Step on the Internet:With cloud service, easy to achieve a variety of network penetrations ,one step to remote monitoring, getting rid of various complicated network settings, easy and simple to operate.
- Compression algorithm ideal:H.264 High Profile compression algorithm,30% decrease of stream due to advanced space-time filtering technology.
- Playback quality: Supports full real-time encoding video, full real-time playback of multi-channel synchronous decoding.
- Main and Sub Stream:Main stream and Sub-stream encoding. Main stream for local storage, ensure image quality; Sub-stream for real-time network transmission, easy to solve bandwidth bottleneck problem.
- Mobile monitor: Support various mobile monitoring(iPhone, Windows Mobile, BlackBerry, Symbian, Android).
- Display: support VGA, HDMI HD output.
- Operation interface:Similar to Windows operating style, easy to get started with powerful mouse right-click function.
- Network:Powerful network services (support DHCP, PPPOE, FTP, DNS, DDNS, EMAIL,IP searches etc.) And perfect support (WEB, Client, SDK), easy to achieve interoperability.
- Browsers:Support IE,Chrome,Firefox,Safari browsers.
- Remote Access:3322 (Greek network), dyndns, oray (peanut shells), myq-see and other Domain Name Services are also provided.
- Differentiation: Boot screen free replacement, more than twenty languages, over 10 sets of GUI interface, ten kinds of remote control, which make our products different from others.
- Others:With unique black box technology, the whole process can be monitored, which greatly reduces maintenance costs.
Specification:
|
Model |
AVR-6308FM |
System |
Main processor |
Hi3531 |
Operating system |
embedded Linux |
|
System resources |
Simultaneous multi-channel real-time recording, playback, network operation, USB backup |
|
interface |
User interface |
support 16-bit true color graphical menu interface and mouse operation |
Preview screen |
1/4/8/9 |
|
Video Standard |
PAL/NTSC(720P) |
|
Video |
Video compression |
H.264(High Profile); JPEG snapshot |
Display quality |
VGA,HDMI:HD (support 1920*1080, 1280*720,1440*900,1280*1024, 1024*768,800*600) |
|
Playback quality |
1080P/720P/D1/HD1/CIF |
|
Encode capacity |
8*720P |
|
Decode capacity |
8*720P |
|
|
Multi-mode input |
Pure analog: 8*720P pure network: 1*1080P+8*720P/4*1080/20*960H analog + network: 4*720P(analog) + 4*720P(network) |
|
Motion Detection |
Each screen can be set to 192 (16 * 12) detection areas; multi-level sensitivity can be set (Limited local channel) |
|
Audio |
Audio compression |
G.711A |
Intercom |
support |
|
Record & playback |
Record mode |
manual>alarm>motion detection>timing |
Playback |
1 ~ 9 channel playback, Local 8 * 720P mode, maximum support 8-channel playback |
|
|
Video Search |
Time, calendar, event, channel |
Storage & backup |
Space occupation |
Video:720P 20G / day* channel; 960H 12 ~ 20G / day * channel; Audio: 691.2M / day * channel |
Video storage |
HDD, network |
|
Backup mode |
Network, U-disk, USB burner, SATA burner |
|
Interface |
Video input |
8ch BNC |
Video output |
1ch VGA, 1ch HDMI |
|
Audio input |
2ch RCA |
|
Audio output |
1ch RCA |
|
Network interface |
RJ45 10M/100M |
|
PTZ control |
1*RS485, Support multiple PTZ protocols |
|
USB |
2* USB 2.0 |
|
HDD |
2*SATA port (Max 4TB/per) |
|
Wireless |
3G, WIFI (extension via USB) |
Image Show:
