Home > Auto, Motorcycle Parts & Accessories > Car Safety > Car DVR > Low Cost Indoor 8ch Ahd Kits

Low Cost Indoor 8ch Ahd Kits

US$ 150 - 210 MOQ: 10 Pieces

Key Specifications

Get Latest Price

Place of Origin:

Guangdong, China

Brand Name:

OEM

Model Number:

AVR-6508A-8F

Contact Supplier Request Quote Chat Now

Shenzhen Newsurway Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

guangzhou/shenzhen/hongkong

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Guangdong, China

Brand Name OEM

Model Number AVR-6508A-8F

low cost indoor 8ch ahd kits

Package Contents :

AVR-6508A AHD Digital Video Recorder 1PCS

TC-3065AS Waterproof Infrared Camera and Bracket 8PCS

Power Supply 2PCS

5 Way power cable spiliter 1PCS

20M Video Cable and DC Cable 8PCS

Product Overview:

AVR-6508A is designed specifically for high-definition field of security surveillance products, applied stable embedded LINUX operating system; It support H.264 video compression and G.711 audio compression technology to achieve high-quality and unique single-frame playback, playback can reproduce the details, which will help detailed analysis. A variety of functions including record, playback, monitoring, synchronized audio-video, advanced control technology and strong network data transmission capacity.

Product Features:

- H.264 Video Standard and G.711 Audio standard

- Support 720P HD preview,recording and playback;

analog video transmission technology, coaxial cable as the transmission medium; Coaxial two-way data Cable send control signals such as head rotation, zoom control, etc;

- Transmission over long distances, 720P via 75-3 coaxial, ensures transmission of 500-meter HD video signals;

- Anti-interference ability,under strong interference environment ensure the transmission of high-definition video display, distortion does not occur, dropped frames;

- Apply a new UI, more intuitive and simple user experience using the menu style 3 full display

- Video features: manual recording, timer recording, motion detection etc; USB interface backup and network backup - support CVBS, VGA and HDMI output simultaneously,VGA, HDMI Full 1080P, to overturn traditional monitor display

- Video playback:4CH ( 2CH real-time+6CH none real-time ) - Network Function: Support TCP / IP, UDP, RTP / RTSP, DHCP, PPPoE, DDNS, NTP and other rich network protocols; support for real-time network monitoring, video playback, and management functions; built-in WEB Server, achieved directly through browser visit to meet One-Key Remote for P2P Cloud Service.

Buck-up Picture:

About Ordering:

Product Information	Product Information
8CH AHD DVR	AVR-6508A

Product	Model No		AVR-6508A
System	Main Board Sensor		Industrial Embedded Microprocessor
	Operating System		Embedded LINUX operating system
Video Spec	Video Coding		H.264
	Coding Resolution	8CH 720P(1280x720)
	Video Frame	PAL:1-25FP/S;NTSC:1-30FP/S
	Video Bit Rate	512Kbps-4096Kbps,Customize,Default to be 2048Kbps
	Stream Type	Video Streaming / Composite Stream
	Double Stream	Support
Audio Spec	Audio Coding	G.711
	Audio Sampling rate	8KHz,16Bit
	Audio Bit Rate	64Kbps
Video Port	Video Input	8CH BNC Port
	Video output	1CH CVBS,1CH VGA output,1CH HDMI port /No On-Ground and matrix output.
Audio Port	Audio Input/Output	4CH RCA Audio Input / 1CH RCA Audio Output
	Audio Intercom	Audio Input-Output Multiplexing
Recording Manage	Recording Mode	Automatic recording, Manual Recording, Motion Detection Recording, Alarm Recording
	Playback	8CH 720P Playback ( 8CH real-time 25fps )
	Backup Mode	Mobile Hard Disk / U-Hard-Disk / Network
Network	Protocol	Support TCP/IP,UDP,RTP/RTSP,DHCP,PPPoE,DDNS,NTP etc.
	IE Control	With WEB Server to modify configuration parameters and remote control IE
	P2P Cloud	Support login via to meet One-Key Remote Control.
	Mobile Remote	Support IOS, Android,Blackberry, Symbion, Software .
HDD	HDD Port	Support 1*SATA port max 4TB,No e-SATA port.
Interface	Network/USB	1* RJ45 port, 100M E-internet Port ; 2PCS USB Port
Others	Power/Consumption	DC12V ; <15W(No HDD)
	Temperature/Humidity	Temperature:-10℃-+55℃ / Humidity: 10%-90%
	Size/Weight	225mm×215mm×55mm / According package Carton

Waterproof Camera Specification:

Model	AHD-3065-AS
Image sensor	1/4" OV9712 CMOS
Signal	AHD-M
Effective pixels	1280*720
Minimum illumination	Color 0. 1Lux @(F1.2,AGC ON),0 LUX with IR
Minimum illumination	B/W 0. 01 Lux @ (F1.2,AGC ON),0 LUX with IR
Shutter	1/50(1/60)S~1/10,000S
IR_CUT	Support IR-CUT
Lens	3.6mm Mega pixels lens
IR Range	36 PCS ¢5 IR Leds / 20 meters IR distance
Video output	1Vp-p Composite Output(75Ω/BNC)
Working Condition	-10℃ - 60℃, Humidity <90%( No condensation )
Power	DC12V±10%
Protection rade	IP66
