| 300kW power generator , truck diesel generator set for sale | |||||||||
| 1. Specification of genset | |||||||||
| Gensets model | TPD378V5 | ||||||||
| Prime power | 300KW/378KVA | ||||||||
| Rated Voltage(V) | 400/230 | ||||||||
| Rated frequency(HZ) | 50 | ||||||||
| Rated Speed(RPM) | 1500 | ||||||||
| Power Factor | 0.8(lagging) | ||||||||
| Dimensions(mm) (L×W×H) | 7000*2200*2400mm | ||||||||
| Genset Weight(kg) | 10000 | ||||||||
| 2. Specification of diesel engine | |||||||||
| Engine brand | VOLVO | ||||||||
| Engine model | TAD1343GE | ||||||||
| Rated power | 323 kW/443 KVA | ||||||||
| Number of Cylinders | 3 | ||||||||
| Cylinder arrangement | In-line | ||||||||
| Cycle | Four stroke | ||||||||
| Aspiration | Turbocharger | ||||||||
| Bore×Stroke (mm×mm) | 131 x 158 | ||||||||
| Compression Ratio | 18:01 | ||||||||
| Speed Governor | Electrical | ||||||||
| Cooling System | Forced Water Cooling Cycle | ||||||||
| Total lubrication system capacity (L) | 44 | ||||||||
| Fuel Consumption at 100% Load (g/kw.h) | 192 | ||||||||
| Starting Method | DC24V electrical starting | ||||||||
| 3. Specification of alternator | |||||||||
| Alternator brand | Stamford | ||||||||
| Alternator model | HCI444F | ||||||||
| Rated power | 302KW/378KVA | ||||||||
| Number of Phase | 3 | ||||||||
| Connecting Type | 3 Phase and 4 Wires | ||||||||
| Number of Bearing | 1 | ||||||||
| Protection Grade | IP23 | ||||||||
| Altitude | ≤1000m | ||||||||
| Exciter Type | Brushless ,Self-exciting, AVR automatic voltage regulating,100% Copper winding wire | ||||||||
| Insulation Class | H | ||||||||
| Telephone Influence Factor (TIF) | ≤50 | ||||||||
| THF | ≤2% | ||||||||
| Voltage Regulation, Steady State | ≤±1% | ||||||||
| Transient State Voltage | ≤-15%~+20% |
||||||||
| ♦ Seaworthy packaging |
| ♦ Main shipping companies |
| ♦ Payment terms: 30% T/T as deposit, 70% balance be paid before shipment or 100% irrevocable L/C at sight |
| ♦ Delivery time: 5-25 days against deposit (according to specific project) |
|
Q1: How is your Warranty? All TONTEK POWER goods are warranted in accordance with our warranty terms for a period of 12 months from date of dispatch or 1,000 running hours from date of commissioning whichever comes earlier. |
|
Q2: Can you supply OEM service? Yes. |
|
Q3: How about the service after sale? We have agents spread all over the world, our service network spanning more than 50 countries so we can ensure fast and good service for our clients. We are recruiting agents, welcome you to be our friend and get a win-win cooperation . |
|
1. In manufacturing of power generators, TONTEK POWER is able to draw on an experience of more than 10 years. Our total production capacity is about 40,000 units per year. |
|
2. The power generator sets are designed for continuous power supply and have proved 10,000 fold around the world in various applications on every continent. |
|
3. Except standard products, we also provide customized design service for you, design generator sets as per your specific requirements. |
|
Tel: +86 523 81556166 Fax: +86 523 81558066 Web: Address: No.19, Hailing Industrial Area, Taizhou City, Jiangsu Province, China 225300 |
