a pair of BIDI WDM single fiber 10/100M 1310/1550 60km fiber media converter
Media converters can be used anywhere in the network to integrate newer technology with existing equipment to support new applications, technologies and future growth. Instead of costly, across-the-board upgrades, media converters can extend the productive life of the existing cabling as well as the active equipment.
POWERLINK supply 10/100Base Ethernet Fiber Media Converters, 1000Base Gigabit Fiber Media Converter,SFP Fiber Media Converter, Options in singlemode dual fiber, multimode dual fiber and singlemode single fiber. We also supply Media Coverter Chassis, like 14 slot media converter chassis and 16 slot media converter chassis, used to manage the various media converters.
Features
- AutoCross™: Automatically detects and configures the twisted pair port on the converter to the correct MDI or MDI-X configuration.
- Link Pass Through: Link Pass Through is a troubleshooting feature that allows the media converter to monitor both the fiber and copper RX ports for loss of signal.
- Automatic Link Restoration: The medio converters will automatically re-establish link in all network conditions.
Selectable speed setting: The converter can be set to 10Mbps or 100Mbps. Both copper and fiber ports are automatically set to the same speed. Devices connect to duplex mode of link partner.
Key Features
- 10/100Mbps auto-negotiation
- Supports IEEE 802.3x full-duplex flow control and back pressure half-duplex flow control
Supports self-learning - Standards: IEEE802.3, IEEE802.3u, IEEE802.3x, 10/100Base-TX, 100Base-FX, 10/100/1000Base-TX, 1000Base-FX/LX
LED status of Link, activity, Full/half duplex, speed and power on diagnostic function - Extremely low power consumption and low heat
- Reliable and stable performance
Specification
| Parameter | Specification | ||||
| UTP Port | 1-port RJ45 | 2-port RJ45 | 4-port RJ45 | 6-port RJ45 | 8-port RJ45 |
| Power Supply | External or built-in | External | External | External | External |
| Dimension (L×W×H) (mm) | 26x70x95 (with external power) | 26*70*95 (with external power) | 30*110*140 (with external power) | 30*110*140 (with external power) | 30x110x140 (with external power) |
| UTP Rate | 10/100Mbps | ||||
| Fiber Port | Simplex SC, ST, FC available | ||||
| Fiber Rate | 100Mbps | ||||
| Fiber Wavelength | 1310/1550nm | ||||
| Fiber Mode | Single-mode | ||||
| Distance | 20km | ||||
| LED Indicator | TX LINK, FX LINK, TX ACT, FX ACT, PWR, FDX. | ||||
| Working Temperature | -20~75°C | ||||
| Relative Humidity | 5%~90% | ||||
Applications:
- Extend Ethernet Network Distances
- It use the 10/100BASE-T to 10BASE-FL speed setting (back-to-back) to extend the distance between two 10/100BASE-T devices up to 100km. using single mode fiber without a repeater.
- Extend Fast Ethernet Network Distances
It use the 100/1000BASE-TX to 100/1000BASE-FX setting to extend the distance between any two 100/1000BASE-TX devices up to 100km. using single mode fiber. Or interface directly with a 100/1000BASE-FX compliant port on any device to provide a 100/1000 BASE-TX port interface.
| transceiver interface | sc,st,lc |
| port | 1 fiber + 1 utp, 1 fiber +2 utp , 1 fiber + 4 utp,1 fiber + 8 utp,2 fiber + 3 utp,2 fiber + 4 utp,2 fiber + 8 utp,2 fiber +16/24utp... |
| speed | 155M 1.25G,10G |
| Distance | 0.5km,20km,40km,60km,80km,100km,120km |
