Galvanized Welded Expanded Metal Mesh Wire Fence

Name: Galvanized Welded Expanded Metal Mesh Wire Fence
Brand: Xiongmai
SKU: 130886525

US$ 2.05 - 5.05 MOQ: 100 Square Meters

Key Specifications

Place of Origin:

Hebei, China

Brand Name:

Xiongmai

Model Number:

XM-GF45

Anping Xiongmai Metal Products Factory

Payment & Shipping

Payment Methods:

Port of Shipment:

New Port Tianjin

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Hebei, China

Brand Name Xiongmai

Model Number XM-GF45

Material Other, Galvanized Iron Wire, Low-Carbon Iron Wire

Type Expanded Mesh

Application Fence Mesh

Hole Shape Square

Aperture 2' to 6'

Wire Gauge 0.71mm-4.5mm

Specifications

1 ISO9001:2000
2 Diameter : 0.5-3mm
3 Thickness:0.3mm-10mm

Anping Xiongmai Metal Products Factory was established in 1996 and has been serving the wire mesh industry for over 15 years. Through our efforts in the past few years, Xiongmai has expanded into a big manufacturer in Anping County of Hebei Province, with an annual output of 1 million tons. Expanded metal mesh can be made from a wide range of materials, chiefly expanded steel mesh, expanded stainless steel and other metal , as steel reinforcement materials in petroleum, chemical industry and building decorations. Thickness available from 0.3mm to 10mm Specification List of Welded Wire Mesh
Opening		Wire Diameter
In inch	In metric unit(mm)	Wire Diameter
1/4" x 1/4"	6.4mm x 6.4mm	22,23,24
3/8" x 3/8"	10.6mm x 10.6mm	19,20,21,22
1/2" x 1/2"	12.7mm x 12.7mm	16,17,18,19,20,21,22,23
5/8" x 5/8"	16mm x 16mm	18,19,20,21,
3/4" x 3/4"	19.1mm x 19.1mm	16,17,18,19,20,21
1" x 1/2"	25.4mm x 12.7mm	16,17,18,19,20,21
1-1/2" x 1-1/2"	38mm x 38mm	14,15,16,17,18,19
1" x 2"	25.4mm x 50.8mm	14,15,16
2" x 2"	50.8mm x 50.8mm	12,13,14,15,16
Technical Note: 1,Standard roll length: 30m;width: 0.5m to 1.8m 2,Special sizes available at request 3,Packing: in waterproof paper in rolls. Custom packing available at request.

Galvanized welded Mesh fenceing
Opening		Wire Diameter
In inch	In metric unit(mm)	Wire Diameter
2" x 3"	50mm x 75mm	2.0mm,2.5mm,1.65mm
3" x 3"	75mm x 75mm	2.67mm,2.41mm,2.11mm,1.83mm,1.65mm
2" x 4"	50mm x 100mm	2.11mm,2.5mm
4" x 4"	100mm x 100mm	2.0mm,2.5mm
Technical Note: 1,Standard roll length: 30m;width: 0.5m to 1.8m 2,Special sizes available at request 3,Packing: in waterproof paper in rolls. Custom packing available at request.
PVC Coated Welded Mesh
Opening		Wire Diameter
In inch	In metric unit(mm)	Wire Diameter
1/2" x 1/2"	12.7mm x 12.7mm	16,17,18,19,20,21
3/4" x 3/4"	19mm x 19mm	16,17,18,19,20,21
1" x 1"	25.4mm x 25.4mm
