Help CenterPlastic Swing Check Valve
Related Products
SHIE YU Professional in PIPE&FITTINGS AND DIAPHRAGM VALVE&BUTTERFLY VALVE&BALL VALVE&CHECK VALVE
SHIE YU Milestones
-1973, Shieyu Group is established in Taichung
1.We have own factoty for over 40 years with good quality and Service.
2.Good Quality: Implement NSF and ISO quality system on all products.
3.Good reputation in Southeast Asian,Middle east, South America market.
4.We have complete product ranges.
UPVC 1/2“~24”
CPVC 1/2”~24”
PPH 12 ~1200mm
HDPE 12 ~1200mm
PVDF 12 ~630 mm
ABS 12 ~630 mm
Standards: DIN, Sch80, Sch40, JIS, BS, or other assigned standards
5.Flexible lead time.
Product Name:Plastic Swing Check Valve
Description:
| 1.Materials: | UPVC/CPVC/PP/PVDF |
| 2.Size Available: | 1/2"(DN15)~8"(DN200) |
| 3.Standard: | ANSI, DIN , JIS |
| 4.Connector: | JW300 |
| 5.Seat Carrier O-Ring: | EPDM/VITON |
| 6.Brand: | SH |
| 7.Color: | Gray/cream-coloured/white |
| 8.MOQ: | 50~100Pieces |
| 9.Production Capatity: | 400Pieces per Month |
| 10.Product Tests: | 100% Tested |
| 11.Certification Available: | NSF/ISO |
Produt Picture:
Material Overview:
1.Material: Polyvinyl Chloride
Symbol: PVC/UPVC
Chemical Compatibility: Withstand low to high levels of chemical corrosions
such as most acids,alkalis,and salt solutions
Max.Temperature Rate: PVC 55°C ~ 60°C
2.Material: Chlorinated Polyvinyl Chloride
Symbol: CPVC
Chemical Compatibility: Withstand low to high levels of chemical corrosions
such as most acids,alkalis,and salt solutions and great
thermal resistance
Max.Temperature Rate: CPVC 95°C ~ 110°C
3.Material:Polypropylene
Symbol: PP
Chemical Compatibility: Excellent chemical resistance of regular acids
Max.Temperature Rate: PP 90°C ~ 110°C
4.Material: Polyvinylidene Fluoride
Symbol: PVDF
Chemical Compatibility: Excellent chemical resistance,and low flame and smoke characteristics
Max.Temperature Rate: PVDF 120°C ~ 150°C
Product Advantages:
1,Non-toxic, ageless, compatible in PH solutions, abrasion-resistant, non-deforming, smooth inner surface, no scaling, less dirt, thermal retention, cold weld, hassle-free installation.
2,Longer performance life, easy and quick maintenance
3,Easy handling, lower installation costs
Typical Application:
UPVC: Pressure water application for non-potable water:
l Purified water
l Agricultural drainage
l Environmental construction
l Industrial air flow system
l Sterile room ventilation
PVDF
♦Highly purified water
♦Sterile room ventilation
♦Highly corrosive liquids
PP----Hot corrosive liquids
CPVC: Under certain pressure water application of industrial solid,liquid,and gas chemicals:
l Oil
l Chemical processes
l Electronics
l Gold
l Papermaking
l Processed foods and beverages
l Pharmaceutical operations
l Industrical plating
l Seawater treatments
l Hot spring water distribution
