Specifications
200Lsteel drum production line or steel barrel making machine1. Beading height:less 14mm
2. Drum height:894-905(mm)
200L steel drum / steel barrel production line
Short introduction:controlled by PLC,hydraulic drive |
|
Main technics: a)Beading height:≤14mm b)Drum height:894-905(mm) c)Hydraulic system pressure:8Mpa d)Air pressure:0.1Mpa e)Machine size:3700x700x1600(mm), |
- Edge Machine
Short introduction:Controlled by PLC,hydraulic drive,equipped with linear rolling guide.
Main technics:
a)Edging height:18.5mm
b)Drum height:894-905(mm)
c)Hydraulic system pressure:8Mpa
d)Air pressure:0.1Mpa
e)Machine size:3440x830x1700(mm),Total weight: 5T
Hydraulic station: a)Machine size:1800x860x1700(mm)
b)Total weight: 1T
c)Motor power: 22KW
- Beading Machine
Short introduction:controlled by PLC,hydraulic drive,equipped with linear rolling guide,speed control value control
the box feeding.
Main technics:
a)Beading height:≤14mm
b)Drum height:894-905(mm)
c)Hydraulic system pressure:8Mpa
d)Air pressure:0.1Mpa
e)Machine size:3700x700x1600(mm),Total weight: 5.5T
Hydraulic station: a)Machine size:1800x860x1700(mm)
b)Total weight: 1T
c)Motor power: 22KW
- Corrugating Machine
Short introduction:controlled by PLC,hydraulic drive,equipped with linear rolling guide,speed control value control
the box feeding.
Main technics:
a)Corrugating height:≤3mm
b) W rib height:≤9mm
c)Drum height:884-895(mm)
d)W rib space:280mm
e)Motor power:11KW
f)Machine size:4500x650x2100(mm),Total weight: 7T
Hydraulic station: a)Machine size:1800x860x1700(mm)
b)Total weight: 1T
c)Motor power: 7.5KW
- Edge-Curling Machine
Short introduction:controlled by PLC,hydraulic drive,7 layers edge curling,equipped with linear rolling
guide,reducer with frequency and on-off control the cam working.
Main technics:
a)Drum height:886-897(mm)
b)Motor power:45KW
c)Machine size:4800x1300x2200(mm),Total weight: 13T
Hydraulic station: a)Machine size:1800x860x1700(mm)
b)Total weight: 1T
c)Motor power: 7.5KW
