Sentry Infrared Thermometer ST-688 HDS Infrared Thermometer

Sentry Infrared Thermometer ST-688 HDS Infrared Thermometer thumbnail-1
Sentry Infrared Thermometer ST-688 HDS Infrared Thermometer photo-1
US$ 360 - 450 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
SENTRY
Model Number:
ST-688
Contact Supplier Request Quote Chat Now
Shenzhen Graigar Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name SENTRY
Model Number ST-688

Specifications

Sentry Infrared Thermometer ST-688 HDS Infrared Thermometer

Sentry Infrared Thermometer ST-688 HDS Infrared Thermometer

Sentry Infrared Thermometer ST-688 HDS Infrared ThermometerSentry Infrared Thermometer ST-688 HDS Infrared Thermometer



ST685,ST688,ST689,ST688 Plus HDS Infrared Thermomete

Product Name: High Performance Infrared Thermometer
Description: The Infrared Thermometer Models ST685, ST688, ST688 PLUS and ST689 are non-contact high performance infrared temperature measuring instruments. Features include a 4 digits backlit dual display LCD, scan/hold/auto function and auto power off (about 6 seconds). To measure a temperature, point the unit at the food or object, pull the measuring trigger and hold. Make sure the target area is larger than the units spot size. The single spot of laser is used for aiming only.
Features:
  • High DS ratio.
  • Backlit dual display LCD.
  • New series for general purposes.
  • Ultra low power consumption in shutdown mode.
  • Extended long time measuring reliability.
  • Laser sighting on/off is switchable.
  • oC or oF selectable.
  • Electronic trigger lock.
  • Temperature data storage.
  • Audible alarms.
Specification:
Specifications ST685 ST688 ST689 ST688 Plus
Distance/Spot Ratio 30:1 50:1 50:1 50:1
Temperature Range -50~ 1000°C(-58~ 1832oF) -50~ 1500°C(-58~ 2732oF)
Accuracy (Assumes Operation Ambient Temperature of 25°C/77°F) ±3oC(±5oF) -50~ -20oC(-58~ -4oF)
±2oC(±3oF) -20~ 100oC(-4~ 212oF)
±2% 100~1000oC(212~1832oF)		 ±3oC(±5oF) -50~ -20oC(-58~ -4oF)
±2oC(±3oF) -20~ 100oC(-4~ 212oF)
±2% 100~1500oC(212~2732oF)
Thermopile 8~14μm
Repeatability ±1oC(±2oF)
Resolution 0.1oC(0.1oF)
Response Time 500ms
Operation Temp 0~50oC(32~122oF),10~90%RH
Auto Power Off Automatically after approx. 6sec
Emissivity Adjustable 0.1~1.0
oC/oF Switchable YES YES YES YES
Backlight YES YES YES YES
Laser Sight Switchable YES YES YES YES
Max/Min/Avg./T YES YES YES YES
Auto-measuring YES YES YES YES
10 point memory YES YES YES YES
Audio Alarm YES YES YES YES
Dual Display YES YES YES YES
Tripod Mount YES YES YES YES
USB Data Output NO NO YES NO
Thermocouple K Type NO NO YES NO
Dimensions 200×127×47 mm
Safety Approval:
  • Far distance temperature monitor.
  • Electrical troubleshooting.
  • Air conditioner.
  • Manufacturing processes of semiconductor technology.
  • Test terminals on circuits.
  • Perform HVAC energy audits.
