YH71 High Temperature Measurement IR Laser Infrared ThermometerYH71 High Temperature Measurement IR Laser Infrared Thermometer
Product Description
High Temperature IR Infrared Thermometer YH71
Features |
Accesories |
|
Optical Resolution (D:S) (50:1) |
Standard |
Standard K-type thermocouple (-40 to 260°C) |
Wide temperature measurement range |
USB data cable |
|
Laser target pointer |
Data communication software (CD) |
|
Readout is °F& °C selectable |
Leather bag |
|
KTC/ infrared thermometers selection |
9Vbattery (6F22) |
|
Temperature Resolution: 0.1°C& 0.1°F |
Optional |
DC 9V power supply |
LCD with double temperature display and 4 bits |
|
|
MAX, MIN, DIF(diffference), average temperature display |
|
|
Emissivity adjustable (0.10 to 1.00) |
|
|
High-temp. And low-temp alarm |
|
|
Data recording (record up to 100 group of data) |
|
|
Response time: 500 mSec |
|
|
Laser power: Less than 1 milli watt |
|
|
Optical Response: 8?m to 14?m |
|
|
Working Voltage: 9V battery |
|
|
SPECIFICATIONS | |||
Function |
Specifications |
YH70 |
YH71 |
Infrared thermometer |
Temperature Range
>510°C 50~510°C 15~50°C -32~15°C Repeat error |
-32~1200°C (-25~2192)°F
±1.5% of reading ±(1.5% of reading+1°C) ±(1.5% of reading+2°C) ±3°C <0.5% of the reading |
-32~1650°C (-25~3000)°F
±1.5% of reading ±(1.5% of reading+1°C) ±(1.5% of reading+2°C) ±3°C <0.5% of the reading |
K-type thermometers |
Temperature Range |
-40~1370°C ±(1.5% of reading+1°C) |
-40~1370°C ±(1.5% of reading+1°C) |
Infrared Thermometer YH68 & 69
Features
Optical Resolution (D:S) (30:1)
Wide temperature measurement
Laser target pointer
Readout °C/°Fdisplay selectable
Temperature Resolution: 0.1°C or 0.1°F
LCD with double temperature display and 4 bits
MAX, MIN, DIF(diffference), average temperature display
Emissivity adjustable (0.10 to 1.00)
High-temp. And low-temp alarm
Data recording (record up to 100 group of data)
Response time: 500 mSec
Laser power: Less than 1 milli watt
Optical Response: 8?m to 14?m
Working Voltage: 9V battery
Dimensions: 140*56*90
Weight: 500g
Accessories: Leather bag*1, 9V battery(6F22) * 1
Specification | ||
|
YH68 |
YH69 |
|
Temperature Range
>510°C 50~510°C 15~50°C -32~15°C |
-32~850°C (-25~1562°F)
±1.5% of the reading ±(1.5% of the reading+1°C) ±(1.5% of the reading+2°C) ±3°C |
-32~1050°C (-25~1922°F)
±1.5% of reading ±(1.5% of the reading+1°C) ±(1.5% of the reading+2°C) ±3°C |
Repeat error |
<0.5% of the reading |
<0.5% of the reading |
