100 psi Mobile Direct Driven Air Compressor

FOB Price

USD $3,200 - $26,000 / Set

1 Set(Min.Order)

Product Details

Condition:	New	Type:	Screw	Configuration:	Portable
Power Source:	Diesel	Lubrication Style:	Lubricated	Mute:	No
Place of Origin:	Chongqing, China	Brand Name:	Hi-sea	Model Number:	HS025-7
Voltage:	24 V	Dimension(LWH):	295312801205 mm	Weight:	556 kg
Certification:	ISO9001, SONCAP, ECTN, COC, CE	Warranty:	1 Year	After-sales Service Provided:	Engineers available to service machinery overseas

Direct Driven Air Compressor:

Mobile Direct Driven Air Compressor

Technical Parameter

1. Air compressor type is HS025-7

2. Working pressure is 0.7 Mpa, 7 Bar, 100 PSI

3. Volume flow is 2.5 m³ /min, 88 CFM

4. Noise is less than 70 dB(A)

5. Diesel engine is Kubota brand

6. Engine power is 19.4 KW

Features

Superior quality, working life for 10 years.

Thoughtful design, various automatic alarm.

Low noise, less than 70 dB(A)

Convernience in maintenance

The Follow Is 0.7 Mpa Mobile Direct Driven Driven Air Compressors Specification.

Compressor		HS025-7	HS036-7	HS050-7	HS055-7	HS079-7
Volume Flow	M3/min	2.5	3.6	5	5.3	7.9
Working pressure	Bar(e)	7	7	7	7	7
Max/min speed	rpm	3000-2400	2400-1500	2400-1500	2750-1850	2000-1400
Noise level(sound presssure)	dB(A)	<70	<80	<80	<70	<80
Capacity of fuel tank	l	32	40	40	80	185
Air outlet valves-qty x size	inches	2XG3/4	2XG3/4	2XG3/4	3XG3/4	3XG3/4 1XG1 1/2
Length with towing device(min)	mm	2729	2630	2630	2200	2862
Length with horizontal towbar	mm	2953	2630	2630	3100	3651
Width	mm	1280	1318	1318	1400	1790
Height	mm	1205	1280	1280	1280	1908
Operational weight(full fuel tank)	kg	556	652	688	960	1500
Engine
Manufacturer		KUBOTA	YTO	YTO	DEUTZ	CUMMINS
Engine type		D1105	YND485G	YSD490G	D2011L03	4BT3.9C80
Cylinders		3	4	4	3	4
Output at nominal speed	KW	19.4	27	35	36	60

Diesel Air Compressor Engine:

0.7 Mpa Mobile Screw Air Compressor Doors:

Lubricated Diesel Screw Portable Air Compresor Air End:

Screw Portable Air Compressor Diesel Engine Picture:

High Effiency Screw Diesel Mobile Direct Driven Air Compessor Working Condition:
