Help CenterKubota Harvester Rubber Track PRO788,Farm Rubber Track,rubber Track for Tractor
Related Products
-
Rubber Crawler for Combine Harvester Machine,crawler LoaderUS$ 200 - 1,200MOQ: 1 Piece -
Small Rubber TrackUS$ 200 - 800MOQ: 1 Piece
-
UHMWPE Wheel for Rubber TrackUS$ 200 - 1,200MOQ: 1 Piece
-
Rubber Crawler Track for Farm Tractor 350x90US$ 200 - 1,200MOQ: 1 Piece
-
Most Accuracy Water Detector ADMT-2SUS$ 1,984 - 2,083MOQ: 1 Set
Specifications
1,Continuous rubber track2,Jointless structure rubber track
3,Good quality with rapid delivery
4,OEM available
Shanghai Kymoon Rubber Co., Ltd. (also known as King Construction Material Co., Ltd.) is a professional supplier of rubber and plastic products. Our over 9 years’ experience in this industry allows us to gain the qualification of providing our customers with high quality products and excellent services.
1. Installation of the Rubber Tracks
A. Too small strength: Easily causes jumping teeth, riding a tooth or steering failure of the guide wheels and supporting wheels and leads to track derailment or escapes.
B. Too large strength: Track wire will be deformed at the elongation by the excessive strain tensile, which will make the pitch changed, and track core iron and the drive wheels abnormally worn, also will make teeth touched and the track broken, the machine power loss larger, track wear exacerbated, belt crack easier as well as the track life shorter. After the track is strained, the maximum sag distance is 10-15mm, just as the pitch below.
2. Attention
In order to extend the life of rubber tracks, please complete the following work:
A. Never turn urgently on the concrete floor, gravel road, or hard and sharp road, in order to avoid speeding up the wearing, twisting and chapping of the rubber track.
B. Try not to work in the rotten field, to avoid rubber track skid and wear.
C. When the stones or other objects come into the crawler and chassis, stop immediately, and clear gravels or obstacles.
3. Warns
A. Do not travel on the road full of footstone, spinous-stone, scrap iron and other objects.
B. Do not drive in the rivers, streams and on the seacast or any rugged road.
C. Do not make the track unilaterial landing.
D. Forbid aggressive driving.
E. Avoid making a turn rapidly, please slow down and make a turn gradually.
4. Maintenance and Service
A. After working in the field of beach or chemicals, flush the rubber tracks in time.
B. Clearing the mud, gravel and debris in rubber tracks.
C. Avoid the rubber track sticking greases, resolver, or salts etc., if so, clean our in time.
D. Always check the functions of various auxiliary parts in tracks, if there is wear seriously, replace it in time.
E. If stored up for a long time, tracks must be washed, dried and hanged up.
Rubber track for agriculture specification:
| Agriculture Machine Specification: | ||
| 1 | 250*72*42 | |
| 2 | 280*90*38 | |
| 3 | 350*90*40 | |
| 4 | 350*90*42 | |
| 5 | 350*90*44 | |
| 6 | 350*90*46 | |
| 7 | 350*90*46(H) | |
| 8 | 350*90*48 | |
| 9 | 350*90*42(H) | |
| 10 | 400*90*40 | half feeding type |
| 11 | 400*90*42 | |
| 12 | 400*90*43 | |
| 13 | 400*90*45 | |
| 14 | 400*90*46 | |
| 15 | 400*90*47 | |
| 16 | 400*90*42(H) | |
| 17 | 425*90*47 | |
| 18 | 400*90*46 | whole-feed type |
| 19 | 400*90*48 | |
| 20 | SB400*90*48 | |
| 21 | 400*90*50 | |
| 22 | 450*90*46 | |
| 23 | 450*90*50 | |
| 24 | 450*90*51 | |
| 25 | 450*90*56 | |
| 26 | 500*90*50 | |
| 27 | 500*90*52 | |
| 28 | 500*90*55 | |
| 29 | 500*90*56 | |
Please kindly contact us for more details.
