Constant Voltage and Constant Current Analog dc Power Supply APR-6402 220V/110V Single Channel Output

 Constant voltage and constant current  Analog dc power supply APR-6402 220V/110V Single channel output

APR Series linear dc adjustable power supply is an equipment with high stability, high reliability, low noise. Both of its output

voltage and current can be continuously adjustable. This low cost and universal power supply can be used in many different

areas, from testing R&D equipment to test products of production lines.

Application:

1.Educational Laboratories
2.Electronic production line
3.Communications industry
4.Product research

5. All other areas need dc power supples

Features:

Single channel output

External and internal radiator cooling design can reduce noise

Pointer meter shows the voltage and current value.

Constant voltage and constant current dc power supply

Specifications:

Model: APR-6402

Input voltage: 220 V or 110V±10% 50/60Hz

Output voltage: 0-64V

Output current: 0-2A

Operating Temperature: 00C to 400C

Relative humidity: <80%

Storage Temperature:-200C to 800C

Relative humidity: <70%

Constant voltage state:

Voltage stability: <0.01%+3mV

Load stability :< 0.01%+5mV

Recovery time :< 100μS

Ripple & noise : <1.0mVrms

Temperature coefficient: < 300PPM/0C

Constant current state:

Current stability:<0.2%+2mA

Load stability:<0.2%+2mA

Ripple & noise: <2mARMS
