High quality hand-held Electrostatic Field meter FMX-003 electrostatic tester

Specifications

High quality hand-held Electrostatic Field meter FMX-003 electrostatic tester

High quality hand-held Electrostatic Field meter FMX-003 electrostatic tester



The FMX-003 measures static voltages within + / -. 22kV (22,000 V) at a distance of 1 "Results are simultaneously displayed numerically and in bar graph format POWER on / off, ZERO adjustment, Ion Balance (IB) and HOLD are. all push button operation. The HOLD button allows the display to retain the static charge reading. This is especially useful where display is difficult to see during measurement. Two LED guide lights help position the fieldmeter at the right distance from a charged test object. The conductive case and ground snap facilitate grounding for accurate measurement. The circuitry of the FMX-003 has been designed to make measurements in areas using air ionization.

Easy to read, easy to use operations
Lightweight, compact design
Range light assures accurate and repeatable measurements
Digital and bar graph display
Automatic power off after five minutes (may be disabled if preferred)
Specifications:
Display Features Push button POWER, HOLD, ZERO and ion balance operation
Read Out Bar graph-red LCD for positive polarity voltage; blue LCD for negative polarity voltage; battery capacity and error display indicators
Measurement Capacity Measuing range: 0 to ± 1.49 kV (low range); ± 1.0 kV to ± 22.0 kV (high range); 0 to ± 220 V (ion balance measuring range)
Measuring Distance 1 "± 1/64" (25mm ± 0.5mm); LEDs gide for correct distance (between charged object and fieldmeter)
Power 9 V, 6F22Y manganese battery
Size 4 7/8 "L x 2 7/8" W x 1 "H [123mm L x 73mm W x 25mm D]
