Specifications
NEW STC-8080A+ Temperature Controller Temperature measuring range: -50~+99oC
NEW STC-8080A+ Temperature Controller Temperature measuring range: -50~+99oC
Product Overview
Suitable for middle-low temperature cold storage,wind cooling cabinet,kitchen cabinet,operating console,refrigerating display cabinet.
Features
To measure, display and control temperature;
Defrosting cycle and defrosting time is adjustable;
Alarm when temperature exceeds setting temperature limit value;
Compressor start up delay protection;
Compressor work as scheduled time when sensor error.
Main Function
Refrigeration,Defrost,1NTC,Temperature Calibration.
Parameter
Power supply:220VAC+10%-15%, 50/60Hz
Power consumption:3W
Temperature measuring range: -50~+99oC
Temperature controlling range: -40~+50oC
Resolution: 1oC
Accuracy: ±1oC when temperature -40~+50oC, ±2oC at others
Relay capacity of compressor: 7A/2240VAC
Sensor error relay time: 1 minutes
Sensor type: NTC sensor.
