Specifications
NEW JH-4 gate management authority of the metal detector door LED display quality certificate of inspection report
NEW JH-4 gate management authority of the metal detector door LED display quality certificate of inspection report
Adopt the most advanced digital detecting technology in the world , JH series scanner gate is special for detecting metal and alloy articles concealed in human body. It is highly safe, widely applicable and highly sensitive with a wide detecting range and a good anti-interference capability. The user can configure the gate according to the size and weight of the article for detection to exclude error alarm for coins, keys, jewelries and belt buckles. It is applicable in the places such as factories, mines, banks and luxuries houses, where expensive metal articles may get lost easily; and places such as airport, customhouse, jails, exhibition halls, where dangerous metal articles are prohibited.
Description:
Easy Assembly
The JH-4 modular design allows for a quick and very simple assembly. only 8 (eight) screws.
are required for.
6 multi zones
JH-4 offers a 6 display area detect for full target coverage on the left, center and right side of the body from head to toe.
Pin point detection with LED lighters on the entrance side of each gatepost.
Overhead Control Unit
LED Display, alarm lights, LED bar graphs and control touchpads plus all wiring, connections and electronics are integrated into the overhead compartment.
Audible and Visual Alarms Audible alarm and Visual LED lights signal when a target has been detected.
High adjustable sensitivity
JH-4 series digital scanner gate is adjustable. In the highest volume, articles as small as a paper clip can be detected and indicated.
Programming protected by Password .
JH-4 is designed for use by authorized personnel with multi-level security codes. It only allows authorized users to change the programming and the settings.
Humless to human body
Using sensitive metal detecting technology is harmless to heartbeat implement in human body, magnetic software, tapes and video recording tapes
Traffic Counter
Counter tracks the number that have passed through the detector, the number of alarms.
Synchronization
Dual channels and DSP circuitry allow several JH series scanner gates to operate simultaneously in close proximity to one another.
Warranty
Limited 12 months, parts and labor
Dimensions
Outer frame: 2.2 X0.79 X0.54m ( H X W X Depth)
Inner frame: 2.0X0.7X0.540m (H X W X Depth)
Electric current: 90-240v AC,50/60 HZ Power: 35VA
Net Weight: about 65kg
work envionment: -30-+45℃
Standard: GB15210-2003
