NEW EJH-14 Metal detector detects the Food and Drug Chemical iron in copper and aluminum stainless steel Full Metal Detectors
NEW EJH-14 Metal detector detects the Food and Drug Chemical iron in copper and aluminum stainless steel Full Metal Detectors
Technical specifications:
The electronic and mechanism design of the series of EJH auto-conveying metal detector is adopted advanced technique in the world, the design is suitable and the appearance is beautiful EJH-14 owns the ability of high sensitivity and stable behavior
Scope of application:
EJH-14 is mainly used for detecting the metal chips inside the sea-food , fishery, noodle, frozen food, , sugar, tea, pharmaceutical products etc.
Product characteristic :
1: Stainless steel shell , anti-erosion and long life span .
2: The conveyor belt is made of nonpoisonous material
3: Strong transport drive, all the products below 25kg can be conveyed to be checked.
4;Quick convey speed, it is specially suitable for pipeline operation.
5: When sensor detect a broken needle or over a diameter 0.8mm iron ball, buzzer will sound and conveyor belt will stop. After that, detected products will be return at hand.
6:The performance of the belt conveyer is complied with the American food sanitation standard (FDA), it can be used for transporting the unpacked food directly.
7: Can match the pipeline operation or automatic control device.
Technical parameters:
1.Inspection window size:
Normal height of inspection window(mm): 120
Normal width of inspection window(mm): 500
The measures of the inspection window which can be designed according customer’s requirement.
2: Sensitivity: Diameter of 0.8 mm steel ball, weight of 1.2-1.5g Lead, copper and other globular metal parts
3: Electrical source: 220V 50Hz
4: Power : 120W
5: Alarm: Audible and visual alarm, automatic stop
6: Normal Size(mm): 1740(L)X900(W)X1030(H)
7: Gross Weight: approx 370Kgs Net Weight: Around 310kgs.
