NEW NDT280S Portable Shore Hardness Tester Roll Hardness Tester
US$ 600 - 900
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
GRAIGAR
Model Number:
NDT280S
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
J34 7 Piece Fillet Weld Set Gage Gauge Welding Inspection Test Ulnar MM & Inch MG11US$ 18 - 25MOQ: 1 Piece -
NEW NDT290 Portable Hardness Tester (with Printing) on the Richter ScaleUS$ 1,350 - 1,550MOQ: 1 Piece
-
NEW NDT230 Portable Hardness Tester Metal Hardness TesterUS$ 500 - 700MOQ: 1 Piece
-
NEW NDT280S Portable Shore Hardness Tester Rolling Durometer Hardness TesterUS$ 600 - 900MOQ: 1 Piece
-
NEW Surface Roughness Meter NDT120 Handheld Surface Roughness MeterUS$ 1,700 - 2,000MOQ: 1 Piece
Place of Origin
Guangdong, China
Brand Name
GRAIGAR
Model Number
NDT280S
Specifications
NEW NDT280S portable shore hardness tester Roll hardness tester
NEW NDT280S portable shore hardness tester Roll hardness tester
Product Introduction:
1.NDT280S roll dedicated Shore durometer hardness testing dedicated to the roll, is a very mature technology portable metal shell Shore hardness;
2. Roll the material down to "cast steel, forged steel, cast iron," the three materials, measuring more professional and accurate;
3. Universal and set in the hardness of all functions of a machine, easy to operate;
4. With high accuracy, software calibration feature, you can set the tolerance limit, convenient batch test;
5. hardness testing out especially for use, most cost-effective a portable Shore hardness.
Application materials:
Cast steel rolls, forged rolls, cast iron rolls
Steel and cast steel, alloy tool steel, stainless steel, gray iron, ductile iron, cast aluminum, copper and zinc alloy (brass), copper-tin alloy (bronze), copper, forged steel.
Application areas:
1. Roll the industry (steel roll, forged steel rolls, cast iron rolls)
2. Especially suitable for large parts and no removable parts site hardness testing
3. The mold cavity
4. heavy workpieces
5. Failure pressure vessel, turbine generator and equipment analysis
6. experimental space is very narrow workpieces
7. bearings and other parts
8. Materials distinguish metal warehouse
9. rapid detection within a wide range of large parts of many measurement sites.
Features:
1. The use of D-precision impact device
2. Professional measuring roll Shore hardness values (new cast steel rolls, forged steel rolls, cast iron roll three materials)
3. Shore (HS), Richter (HL), Brinell (HB), Rockwell (HRC / HRB / HRA), Vickers (HV) and other seven kinds of hardness values to achieve a measurement, automatic conversion
4. Indication of software with power calibration function to ensure accurate data is applicable in any industry with different norms and standards
5. Optional seven different impact devices, without replacing the calibration, automatic identification
6. Under the pre-set limit values, limit alarm
7. Can store 500 sets of measurement values the whole Chinese menu, backlit display, easy to operate
8. equipped with data processing software, via USB2.0 interface, can exchange data with a computer print and parameter settings.
Detailed parameters:
1. Measuring range: (30 ~ 110) HS, (170-960) HLD, (19-651) HB, (13-100) HRB, (17-68.5) HRC, (59-85) HRA, (80- 976) HV customers to customize
2. Hardness standard: Shore (HS), Richter (HL), Brinell (HB), Rockwell B (HRB), Rockwell C (HRC), Rockwell A (HRA), Vickers (HV)
3. Measuring direction: support 360 ° (vertical downward, oblique, horizontal, oblique, straight up)
4. Optional impact device: D, DC, DL, C, D + 15, E, G
5. Set the upper and lower range: (170-960) HLD
6. Test Accuracy: Indication error ± 4HLD, Repeatability ± 4HLD
7. Data Storage: up to 500 groups (impact times 32 ~ 1)
8. Display: LCD, 128 × 64 dot matrix LCD
9. Operating voltage: 2 × 1.5V ordinary alkaline batteries
10. Dimensions: 125 × 71 × 27mm (host)
11. Weight: about 0.3kg (host)
Working conditions:
1. Working temperature: -10 ℃ ~ + 55 ℃;
2. Storage temperature: -20 ℃ ~ + 75 ℃;
3. Relative humidity ≤90%;
4. surroundings no vibration, no strong magnetic, non-corrosive medium and severe dust.
