Home > Instruments & Meters > Physical Measuring Meter > Hardness Tester > NEW NDT290 Portable Hardness Tester (with Printing) on the Richter Scale

NEW NDT290 Portable Hardness Tester (with Printing) on the Richter Scale

Name: NEW NDT290 Portable Hardness Tester (with Printing) on the Richter Scale
Brand: GRAIGAR
SKU: 130816795
Availability: InStock

NEW NDT290 Portable Hardness Tester (with Printing) on the Richter Scale thumbnail-1

NEW NDT290 Portable Hardness Tester (with Printing) on the Richter Scale photo-1

US$ 1,350 - 1,550 MOQ: 1 Piece

Key Specifications

Get Latest Price

Place of Origin:

Guangdong, China

Brand Name:

GRAIGAR

Model Number:

NDT290

Contact Supplier Request Quote Chat Now

Shenzhen Graigar Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Guangdong, China

Brand Name GRAIGAR

Model Number NDT290

Specifications

NEW NDT290 portable hardness tester (with printing) on the Richter scale

NEW NDT290 portable hardness tester (with printing) on the Richter scale

Product Introduction:

Portable Hardness Tester | print one -NDT290 Kai Dake Instrument 2013 heavy launch high-end portable hardness tester printing machine, user-friendly print test results, especially for use outside hardness testing is cost-effective a portable hardness tester. The instrument uses a streamlined ergonomic design, with a standard stent, using a large-screen OLED 128 × 64 dot matrix display, information-rich and intuitive. No dead ends, easy to operate and read values.

Application areas:

1. machining industry

2. Especially suitable for large parts and no removable parts site hardness testing

3. The mold cavity

4. heavy workpieces

5. Failure pressure vessel, turbine generator and equipment analysis

6. experimental space is very narrow workpieces

7. bearings and other parts

8. Materials distinguish metal warehouse

9. rapid detection within a wide range of large parts of many measurement sites

Features:

1. Design standards: "Leeb hardness tester technical conditions" B / T 9378-2001; the impact of the use of D-precision equipment;

2. industrialized housing design, rugged, compact, portable, high reliability,

3 for harsh operating environment, anti-vibration, shock and electromagnetic interference;

4. Shore (HS), Richter (HL), Brinell (HB), Rockwell (HRC / HRB / HRA), Vickers (HV) and other seven kinds of hardness values to achieve a measurement, automatic conversion;

5. Large-capacity NiMH rechargeable batteries and charging control circuit, the remaining battery indicator, charging indicator, keep abreast of the charge level;

6. Has the boot indication software calibration function to ensure accurate data is applicable in any industry with different norms and standards;

7. Optional seven different impact device replacement without calibration, automatic identification;

8. Can preset limit under value limit alarm;

9. 600 sets of measurement values can be stored in a full menu, backlit display, easy to operate;

10. Can be equipped with a powerful computer software, with transmission measurements, the measured value storage management, statistical analysis of the measured values,

Print measured value reporting and other rich features to meet the higher requirements of quality assurance activities and management;

11. Continuous working less than 200 hours (without printing), automatic sleep, automatic shutdown and other power-saving features.

Technical parameters:

1. Measuring range: (30.6 ~ 102.6) HS, (170-960) HLD, (19-651) HB, (13.5-101.7) HRB, (17.9-69.5) HRC, (59.1-88) HRA, (80- 1042) HV

2. Measuring direction: support 360 ° (vertical downward, oblique, horizontal, oblique, straight up)

3. The system's hardness: Shore (HS), Richter (HL), Brinell (HB), Rockwell (HRC / HRB / HRA), Vickers (HV) and other seven kinds

4. Indication error: D-type impact device ± 6HLD (Indication error)

5. Repeatability: ± 6HLD (Repeatability)

6. limit setting range: (170-960) HLD

7. Data storage: 600 set of measurements

8. Data Interface: USB2.0

9. Display: large-screen LCD high-brightness OLED display
