Home > Instruments & Meters > Test Instrument > Test Machine > MS7282 AC DC Process Calibrator With True RMSK-type With LED Screen Blacklight

MS7282 AC DC Process Calibrator With True RMSK-type With LED Screen Blacklight

US$ 230 - 280 MOQ: 1 Piece

Key Specifications

Get Latest Price

Place of Origin:

Guangdong, China

Model Number:

MS7282

Contact Supplier Request Quote Chat Now

Shenzhen Graigar Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Guangdong, China

Model Number MS7282

Specifications

MS7282 AC DC Process Calibrator with True RMSK-type with LED screen blacklight

Product Description

MS7282 AC DC Process Calibrator with True RMSK-type with LED screen blacklight

FEATURES:

MS7282 This meter is a portable and specialized process verification instrument, which presents as a digital verification meter that has both digital multimeter and signal source function, and can measure and output signal simultaneously. Its large liquid crystal digital display can show and measure the output signal value at the same time, and it is equipped with backlight which makes the user easier to read the value. It uses large-capacity rechargeable battery pack and is featured with low voltage indication. Charging and operating for this instrument can be conducted simultaneously (with a charger). Signal output and measurement function of the instrument is mainly designed for on-site verification and service of an instrument in industrial automation field. This instrument is also featured with multimeter function, which makes it an ideal option for field meterman, computer distributed control system maintainer, meter mounter, and can be used as a multimeter by the meterman.

Specifications

Current Measurement		Range:	0-400mA DC		0-400mA AC
		Resolution:	0.1 mA		0.1 mA
		Accuracy:	0.1% Rdg + 5LSD		1% Rdg + 5LSD
Voltage measurement		Range:	1000VDC		0-700 VAC
		Resolution:	1.0 V		1.0 V
		Accuracy:	0.1% Rdg+5LSD		0.8% Rdg + 5LSD
Frequency measurement		20Hz to 50 kHz, 0.05% + 5LSD
Resistance measurement		to 4 MΩ , 0.3% Rdg + 5 LSD; 4 MΩ to 40 MΩ 0.5% + 50 LSD
Capacitance measurement		to 100 F , 2.0 % Rdg + 10LSD
Temperature measurement		K-type Thermocouple (optional).
Diodemeasurement		2.4 V shows diode voltage drop

Current Sourcing	Range:		0-22 mA
	Accuracy		0.1% Rdg + 5LSD
	Drive Capability:		1000 Ω @ 20 mA
DC voltage signal output	Range:		10VDC			100mVDC
	Resolution:		10mV			0.1mV
	Accuracy:		0.1% Rdg+5LSD			0.1% Rdg+5LSD
Frequency signal output	Range:		100Hz	1KHz			10KHz
	Resolution:		0.01Hz	0.1Hz			1Hz
	Accuracy:		0.1Hz	0.5Hz			5Hz
24DC voltageSourcing	Accuracy: 2% ; Drive Capability: 30 mA
