Specifications
MS7206 Current&Voltage Process Calibrator,Loop calibrator with LCD display
MS7206 Current&Voltage Process Calibrator,Loop calibrator with LCD display
instrument features
Loop Calibrator MS7206 Functions and features
LCD display with font height 22mm.
Over range displays “1”.
Power output 24V DC, which can serve as the working power of 2-wire instrument.
0-10V, 0-20mV, 0-100mV, 0-20mA and 0-22mA DC signal output scales are available, which can serve as the input and output signal of type II and type III instruments and can simulate various of type II and type III instruments in field verification.
200V, 20V, 200mV, 100mA and 20mA DC signal measuring scales are available, which can be used to measure the working voltage of the instrument and the input/output voltage signal and current signal of the instrument.
The instrument can working under condition of 24V power, output DC signal and measuring function simultaneously.
The instrument has quadruple half digits LCD display, with the rotary switch, it can display the output value, measured value and unit
technical_parameters
Specifications
| Current Measurement | Range: | 0 to 22 mA |
| Resolution: | 0.001 mA | |
| Accuracy: | 0.05% Rdg + 4LSD | |
| Current Sourcing | Range: | 0 to 20 mA |
| Accuracy: | 0.05% Rdg + 4 LSD | |
| Drive Capability: | 1200 Ω; 950 Ω at 20 mA | |
| Voltage measurement | Range: | 0 to 200 mV DC |
| Resolution: | 0.1 mV | |
| Accuracy: | 0.05% Rdg + 4 LSD | |
| Voltage Sourcing | Range: | 0 to 10 V DC |
| Resolution: | 1 mV | |
| Accuracy: | 0.05% Rdg +4 LSD |
