CCTV Tester IP&Analog Camera Testing TDR Tester L-T2603T Digital Multimeter UTP Cable Testing POE Test PTZ Wire Tracker

Name: CCTV Tester IP&Analog Camera Testing TDR Tester L-T2603T Digital Multimeter UTP Cable Testing POE Test PTZ Wire Tracker
Brand: Graigar
SKU: 130815697
Availability: InStock

CCTV Tester IP&Analog Camera Testing TDR Tester L-T2603T Digital Multimeter UTP Cable Testing POE Test PTZ Wire Tracker thumbnail-1

CCTV Tester IP&Analog Camera Testing TDR Tester L-T2603T Digital Multimeter UTP Cable Testing POE Test PTZ Wire Tracker photo-1

US$ 320 - 370 MOQ: 1 Piece

Key Specifications

Get Latest Price

Brand Name:

Graigar

Model Number:

L-T2603T

Contact Supplier Request Quote Chat Now

Shenzhen Graigar Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Brand Name Graigar

Model Number L-T2603T

Specifications

CCTV Tester IP&Analog Camera Testing TDR tester L-T2603T Digital Multimeter UTP Cable Testing POE Test PTZ Wire Tracker

Features

English, Chinese and other languages optional
3.5'' TFT-LCD, 480(RGB)x320
LED Lamp, easy to operate at night.
Micro SD card moveable
User-defined shortcut keys (F1 and F2)
LCD screen brightness/contrast/color saturation adjustable
Automatically adapts and displays the video format of NTSC/PAL
10x zoom, video image can be magnified to view the details, easy to use
Video record and playback
Snapshot and save the current images as JPG file in the SD card
PING testing, test IP camera or other network devices’ ethernet port whether work normally, and the IP address whether right
IP address scan, quickly search the IP address for the connected IP camera and other network devices.
POE voltage measurement, test the PoE switch’s voltage to IP cameras, wireless AP device and other PD devices
Device Port flicker, easy to find the connected PoE switch port by sending special signals, the connected PoE port will flicker at special frequency.
Link monitor; check the setting IP address whether occupied.
TDR break point and short- circuit measurement(BNC cable, network cable etc)
PTZ address scan, search up the ID of PTZ camera
Network cable and Telephone cable testing, display the sequence of connection and the NO of the LAN cable
Support RS232/RS485/RS422, Rate 600~115200bps adjustable
Multi-protocol. Support more than thirty PTZ protocols. Such as PELCO-P, PELCO-D, SUMSUNG
PTZ protocol analysis, control protocol command displays to check RS485 transmission whether is normal, easy to find the fault device
PTZ control. Pan/tilts the P/T units, zooms in/out the lens, adjusts the focus, aperture and sets and the preset position
DC12V 1A power output for camera
Audio input test, test the audio signal from pickup devices
Visual fault locator, to test fiber’s bending and breakage
Lithium Ion Polymer Battery. The device employs advanced power control and protection circuit. The device is high power-efficient, energy saving and environment protection. It can last 11 hours for normal use after charging for 4-5 hours.

Specification

Video Test
Signal mode	NTSC/PAL(Auto adapt)
Display	3.5 inch digital TFT-LCD, 480(RGB)x 320 resolution
LCD adjustment	Brightness, Contrast, Saturation adjustable
Video IN/OUT	1 channel BNC input& 1 channel output
Video Output Mode	1.0 Vp-p
Video Level test
Level test	Video signals measured in IRE or Mv
PTZ controller
Communication	Support RS232 and RS485
PTZ Protocol	Compatible with more than 30 protocols such as PELCO-D/P, Samsung, Panasonic, Lilin, Yaan, etc.
Baud Rate	600, 1200, 2400, 4800, 9600, 19200, 57600, 115200bps
Video Signal Generation
Color bar generator	Output one channel PAL/NTSC color bar video signal for testing monitor or video cable(red, green, blue, white and black color)
UTP Cable tester
UTP cable test	Test UTP cable connection status and display in the screen. Read the number of the test box.
DC12V 1A power output
DC12V power output	Output DC12V1A power for camera
Audio input test
Audio input test	test the pickup and other audio equipments on the front-end
RS485 data analysis
Data Monitor	Captures and analyzes the command data from controlling device
10x Zoom Image
Image 10x zoom	10x zoom image display and video out
Photograph, Video record,Record playback
Photograph	snapshot and save the current image as JPG file
Video record	Video record and storage the file
Record playback	To view the storage file in the SD card
Port flicker
Port flicker	Find the connected POE port quickly
IP scan, Link monitor, PING test
IP scan	Find out the connected IP camera or the other network equipment IP address quickly
Link monitor	Check the IP address whether is occupied
PING testing	Test IP camera or Ethernet port of the other network equipment whether work normally, and check the IP address
Cable scan
Cable scan	Search the cable by the audio signal
PoE tester
PoE tester	Display the power supply voltage and cable connection states
Digital Multimeter
AC/DC Voltage	0~660V auto/manual range, the min resolution is 0.1 mV
AC/DC current	660.0uA, 6.600mA, 66.00mA, 660.0mA, 10.00A
Resistance	660.0Ω, 6.600KΩ, 66.00KΩ, 660.0KΩ, 6.600MΩ, 66.00MΩ
Capacitance	6.6nf~66000uf, the min resolution is 1pf
Diode	0~2V forward voltage, the min resolution is 1mV
Data hold	Hold and display the measured value
Relative measurement	Display the relative power value
Continuity testing	Built-in buzzer will sound, if resistance is lower than 50Ω
Testing speed	3 times/second
Data range	-6600~+6600
Optical power meter
Calibrated Wavelength(nm)	850/1300/1310/1490/1550/1625nm
Power range(dBm)	-70~+10dBm
Sensitivity(nW)	0.001nW
Connector type	FC/PC
Data hold	Hold and display the measured value
Relative measurement	Display the relative power value
Visual fault locator
Visual fault locator	Test fiber's bending and breakage(SM and MM fiber)
TDR Tester
TDR Tester	breakpoint and short circuit measurement(BNC cable, telephone cable)
Power
Power adapter	DC 5V(1.5A)
Battery	Built-in 3.7V lithium polymer battery, 3000mAh
Rechargeable	After charging 3-4 hour, working time lasts 11 hours
Low Consumption	Energy saving technology, the battery icon real-time display
Parameter
Operation setting	English/Chinese and other languages OSD menu
Auto off	5-60(mins)
Keytone	On/Off
General
Working Temperature	-10ºC~50ºC
Working Humidity	30%~90%
Dimension/Weight	300mm x 250mmx 120mm/2kg

Comparison among L-T26xx series

There are function differences among our 18 models of CCTV testers and for details, please refer to below table. The only difference between L-T26xx and L-T26xxT is L-T26xxT is with TDR test function while L-T26xx is without this function. Please make sure you are ordering what you really want. Thanks.
