MS5910 Electric Leakage Detector Tester RCD/LOOP Tester Circuit

Name: MS5910 Electric Leakage Detector Tester RCD/LOOP Tester Circuit
Brand: Graigar
SKU: 130815411
Availability: InStock

US$ 110 - 140 MOQ: 1 Piece

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

Graigar

Model Number:

MS5910

Shenzhen Graigar Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name Graigar

Model Number MS5910

Power Electronic

MS5910 electric leakage detector tester RCD/LOOP Tester Circuit

Product Description

SPECIFICATIONS		RANGE		ACCURACY	RESOLUTION
Tripping time		x1 IΔN300(slow 500ms) x5 IΔN40ms(slow 150ms)		±3ms	0.1ms
Tripping Current		(0.2-1.1)IΔN		±0.1IΔN	0.5IΔN
Contact Voltage		0~99.9V		±(10%+0.2V)	0.01, 0.1V
Alternating Voltage (UI-N,UL-L,UL-E)		0~440V		±(3%+3V)	1V
Frequency		DC,45~65Hz		±1Hz	1Hz
Loop Resistance(RL)		0.1~2000Ω		±(10%+0.2d)	0.1Ω
RL Current Test		0.51 IΔN		±(10%+10d)	0.5IΔN
Multiplying Power of Measuring Current		x0.5,x1,x5
Current Level(IΔN)		10mA,30mA,100mA 300mA,500mA
Trigger Phase Angle		0°or 180°
FEATURE	Auto Power Off		√
	Display Back Light		√
	Data logging And recall		100groups
	Low Battery indication		√
	USB2.0 Interface		√
GENERAL
Power Supply	6x1.5v AA batteries
Product Size	180mm x 140mm x65mm (7.1” x 5.5” x 2.6”)
Product Weight	950g(2.0lb)
Category	CE ETL CAT.Ⅲ300V RoHS
