Home > Instruments & Meters > Test Instrument > Test Machine > NEW Digital Voice Rebound Hammer HT225-V Infrared Printing Color USB Interface

NEW Digital Voice Rebound Hammer HT225-V Infrared Printing Color USB Interface

Name: NEW Digital Voice Rebound Hammer HT225-V Infrared Printing Color USB Interface
Brand: GRAIGAR
SKU: 130815487
Availability: InStock

NEW Digital Voice Rebound Hammer HT225-V Infrared Printing Color USB Interface thumbnail-1

NEW Digital Voice Rebound Hammer HT225-V Infrared Printing Color USB Interface photo-1

US$ 1,500 - 2,000 MOQ: 1 Piece

Key Specifications

Get Latest Price

Place of Origin:

Guangdong, China

Brand Name:

GRAIGAR

Model Number:

HT225-V

Contact Supplier Request Quote Chat Now

Shenzhen Graigar Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Guangdong, China

Brand Name GRAIGAR

Model Number HT225-V

NEW Digital voice rebound hammer HT225-V infrared printing color USB interface

Traits:

1)The test hammer is combined with displayer part, easy to operate and make your work efficient.

2)LCD color screen 176*220 (other manufacturers’ are black and white, low resolution)

3)Large capacity rechargeable lithium battery, economic and environment protection, long use life, better than other market product (one time use battery)

4)No-touch metal reflect grating and reflect compile sensor, better accuracy. (other manufacturer’s are ordinary transmission grating and optical coupler, or carbon film and brush touch sensor)

5)Born with voice service, color screen display and traditional scale, more accurate, in case power off when site work, we still can make use of the scale to continue work. Voice service can make your work efficient. (similar product of other manufacturers’ in market no voice service and scale)

6)USB interface, easy to connect with PC

7)The software can set rebound value from upper limit to lower limit, and the abnormal date will be deleted automatically.

8)Equipped with infrared portable printer, on site print test report.

9)Some important components are processed from imported materials, after our excellent processing, the instrument get longer use life, better than other similar products

Parameters:

1.test range:10-60Mpa

2.standard impact energy:2.207J.

3.rigidity of tension spring:785N/M.

4.stroke of rebound hammer: 75mm.

5.error range for digital displayer:≤±0.5(the difference between displayer and scale)

6.average rebound hammer on steel anvil Rm:80±2.

7.Screen:16bit true color,176*220resolution,5 classes back light choose.

8.Storage:255*100*16=408000 test points, customer can add up to 20 test curves.

9.Power source:3.6V/1300mAH Li battery,charger adapter 5V/2A.under largest back light and shut down the voice, last work 13 hours.

10.Power consumption:largest back light≈100mA(voice shut down).

nnect interface:USB2.0

12.weight:1.1Kg.

After careful comparing all the test hammers in market. Test hammer manufactured by us is better, and you will find our price is better too.

Compare between HT225-V digital test hammer and other digital test hammer:

Items	Our HT225-V	Similar product in market	Our advantage
Displayer part and test hammer	integrated	Divided	We are pioneer in China, make test work efficient
Test method of sensor	Metal reflect grating, reflect compile sensor	Ordinary transmission grating, optical coupler sensor	Our product equipped with advanced sensor, make the test accurate, our tech is the most advanced in China
Screen of displayer	True color LCD 176*220 resolution	Black and white	We are the first corporate that take the color LCD into test hammer
Voice function	Yes	No	We are more considering in user
Voice function	Large capacity Li battery	Alkaline battery	Reusable, environmental protect and long use life
