Home > Instruments & Meters > Electronic Instrument > Oscilloscope > CP8300A Perfectly Compatible With the Current Probe Tektronix 300A Oscilloscope

CP8300A Perfectly Compatible With the Current Probe Tektronix 300A Oscilloscope

Name: CP8300A Perfectly Compatible With the Current Probe Tektronix 300A Oscilloscope
Brand: Graigar
SKU: 130814935
Availability: InStock

CP8300A Perfectly Compatible With the Current Probe Tektronix 300A Oscilloscope thumbnail-1

CP8300A Perfectly Compatible With the Current Probe Tektronix 300A Oscilloscope photo-1

US$ 2,800 - 3,200 MOQ: 1 Piece

Key Specifications

Get Latest Price

Place of Origin:

Guangdong, China

Brand Name:

Graigar

Model Number:

CP8300A

Contact Supplier Request Quote Chat Now

Shenzhen Graigar Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Guangdong, China

Brand Name Graigar

Model Number CP8300A

Summary

The CP8000A series uses a combination of Hall effect and transformer technology which enables measurements to be made on DC, AC and impulse currents. It’s key features include highly accurate current measurements,wide bandwidth,easy current measurements,DC/AC measure,over-current protected and indication(buzzer and LED indicator),double ranges selection,low current measurements,degauss and auto zero function.

CP8300A has a 6 MHz bandwidth and is designed to measure continuous currents up to 300 Amp.

Key features

• Highly accurate current measurements
• Easy current measurements
• Wide bandwidth
• DC/AC measure
• Over-current protected

Application

switching power supply
LED lighting design
Semiconductor Devices design
Inverter/ transformer design
electronic ballast design
engine driven design
electric vehicle design

Parameter	CP8300A
BW(-3dB)	DC-6MHz(see Fig.7)
Rise time	58ns or less
Continuous maximum input range	300Arms (Frequency derating see Fig. 8)
Max peak current value	500A
Range	50A	10X
	300A	100X
Over	50A	≥50A
	300A	≥500A
Current Transfer Ratio	50A	0.1V/A
	300A	0.01V/A
Lowest Measurable Current	50A	5mA
	300A	50mA
Amplitude accuracy (DC,45-66Hz )	50A	±1%±10mA
	300A	±1%±100mA
Input impedance	see Fig.9
Power Supply	DC 12V/1.2A
Safety standards	IEC61010-1: 2010 IEC61010-2-32: 2012 EN61010-1: 2010 EN61010-2-32: 2012
Max. rated voltage to earth	600V CATII 300V CATIII
