SA3602A Automatic Distortion Meter

Name: SA3602A Automatic Distortion Meter
Brand: Suin
SKU: 130814673
Availability: InStock

US$ 800 - 920 MOQ: 1 Piece

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

Suin

Model Number:

SA3602A

Shenzhen Graigar Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name Suin

Model Number SA3602A

SA3602A Automatic Distortion Meter

FEATURES

l Automatic switch of range and unit, and automatic position of decimal

l Synchronous measurement of distortion, frequency and level

l LED with double 4-bit digit display

l The Lissajou’s figure of input signal can be measured through the external-connection oscilloscope terminal

SPECIFICATIONS

Measurement Range	SA3602A Distortion Meter
Distortion	Frequency: 20 Hz ~20 kHz
	Voltage: 100 mVrms ~300 Vrms, automatic measurement
	Measurement Range: 0.01%~50% Remain Distortion < 0.03%
	2nd Harmonic Accuracy: within ±1 dB ( fundamental frequency between 20 Hz and 20 kHz)
	Fundamental Rejection: 80 dB
	Maximum Input Voltage: DC+AC < 400 V p-p
Voltage	Frequency: 10 Hz ~200 kHz
	Voltage: 3 mVrms ~300 Vrms
	Accuracy: within ±4%(at 1kHz), automatic measurement
	Remain Noise: <50 μV (input short-circuit)
	Input Impedance: 100 kΩ±10%
Frequency	Range: 10 Hz ~200 kHz
Frequency	Error: within ±2 digits
General Characteristics
Power: 220(1±10%) V; 50 (1±5%) Hz; ≤10 VA Working Environment: Temperature: 0 ℃~+40 ℃; Humidity: (20 ~90)%(40 ℃); Atmospheric Pressure: 86 kPa ~106 kPa Dimensions: 254×115×384 mm Weight: Approx. 3.8 kg
