SS7200A Universal Frequency Counter/Timer

US$ 880 - 1,000 MOQ: 1 Piece

Key Specifications

Place of Origin:

Guangdong, China

Model Number:

SS7200A

Shenzhen Graigar Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Model Number SS7200A

SS7200A Universal Frequency Counter/Timer

Features

High accuracy with minimum measuring resolution 10 digits/s
Single resolution can reach 500ps for measurement
200MHz frequency measuring for CH1 and CH2
Maximum frequency’s measurement can reach to 16GHz (options)
16-bit microcontroller is used and the speed of data processing is fast.
With the statistics functions of multi-average, maximum, minimum, PPM, standard deviation and Allan Variance for frequency measurement
High-stability crystal oscillator is optiona

Specifications

			SS7200A		SS7300
Resolution			8 digits /s		10 digits/s
Frequency		CH1	0.001Hz ~ 200 MHz
		CH2	0.001Hz ~ 200 MHz
		CH3	Optional: 3GHz;6.5GHz;12.4GHz; 16GHz
Period		CH1	5ns ~10000s		5ns ~1000s
		CH2
Dynamic Range			50mVrms~1.0Vrms (Sine); 150mVP-P~4.5VP-P (Pulse)
Pulse Width			30ns~5000s
Duty Cycle			1~99%
Totalize			0~1 ×10¹³
Phase Difference			0°~+360°
Time Interval			10ns~10000s
Input Coupling			AC or DC
Input Impedance			50Ω or 1MΩ
Interface		Standard	USB		USB, RS-232
		Option	RS-232, GPIB		GPIB
General characteristics
Power conditions			AC220V(1±10%), 50Hz(1±5%), <35VA
Dimensions & Weight			375×105×235mm, Approx. 3.7kg

OXCO			Standard		Optional
Nominal Frequency			10MHz		10MHz
Accuracy			5×10^-8		5×10^-8
Daily Aging			1×10^-8/day		5×10^-10/day

Option	Frequency Range			Dynamic Range
3GHz	100MHz~3GHz			-27dBm~+19dBm Sine (Frequency: 100MHz~2.6GHz) -15dBm~+19dBm Sine (Frequency: 2.6GHz~3GHz)
6.5GHz	200MHz ~6.5GHz			200MHz~400MHz -15dBm~+13dBm 400MHz~6.5GHz -20dBm ~+13dBm
12.4GHz	6.5GHz ~ 12.4GHz			-18dBm~+10dBm
16GHz	6.5GHz ~ 16GHz			6.5GHz~12.4GHz -18dBm ~ +10dBm 12.4GHz~16GHz -15dBm ~ +10dBm
