Digital Function Generators UTG9003C 2MHZ 25Vp-p signal generator small



Digital Function Generators UTG9003C 2MHZ 25Vp-p signal generator



Detailed

UT9000C series, can produce sine, square, triangle, pulse wave, sawtooth and other waveforms, wide frequency range up to 5MHz, having a DC level adjustment, adjust the duty cycle, VCF function, with TTL-level output, at the same time display the output signal, the amplitude and frequency can be used as a frequency counter external frequency measurement, the series has excellent frequency characteristics, square wave rising ≤50nS, all the electrical performance indicators have reached the level of similar foreign products



Contrast

Features Range
Model UTG9002C UTG9003C UTG90005C UTG9010C
Waveforms Sine, Square, Triangle, Ramp, Pulse, TTL etc.
Amplitude
Range (no load) from 1mVpp to 20Vpp from 1mVpp to 25Vpp from 1mVpp to 20Vpp from 1mVpp to 20Vpp
Accuracy ±5%
Resolultion 0.1mV
Frequency
Range from 0.2Hz to 2MHz from 0.2Hz to 2MHz from 0.5Hz to 5MHz from 1Hz to 10MHz
Accuracy ±1%
Resolultion 1mHz
Output Power 2Wp-p 4.5W (Power output) 2Wp-p 2Wp-p
Output Impedance 50Ω 1Ω (Power output) 50Ω 50Ω
Attenuator 20dB + 40dB
DC Offset from -10V to +10V
Display Frequency: 4-digits-LED, Amplitude: 3-digits-LED
Duty Cycle from 10% to 90%
Distortion of Sine ≤2% (at 1kHz)
Rise time of Square ≤50ns ≤50ns ≤35ns ≤35ns
VCF ≥100:1 No ≥100:1 ≥100:1
Frequency Counter
Frequency Range from 0.2Hz to 10MHz
Amplitude Range from 0.5Vp-p to 5Vp-p
Input Impedance 10kΩ
General Characteristic
Power AC 220V,50Hz
Product Color White and Gray
Product Net Weight 2.5 Kg
Product Size 320mm×240mm×100mm
Standard Accessories BNC to Alligator Clips,Power Cord
Standard Individual Packing Gift Box,English Manual
Standard Quantity Per Carton 6 Pcs
Standard Carton Measurement 660mm×410mm×600mm
Standard Carton Cross Weight 18 Kg

Fitting

BNC to Alligator Clips;
Power Cord.
