Home > Instruments & Meters > Test Instrument > Test Machine > Safety Testers UNI-T UT527 Handheld Battery Powered Tester Meter

Safety Testers UNI-T UT527 Handheld Battery Powered Tester Meter

Name: Safety Testers UNI-T UT527 Handheld Battery Powered Tester Meter
Brand: UNI-T
SKU: 130811587

US$ 100 - 150 MOQ: 1 Piece

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

UNI-T

Model Number:

UT527

Shenzhen Graigar Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name UNI-T

Model Number UT527

Safety Testers UNI-T UT527 Handheld Battery Powered Tester Meter

Detailed

UT527 is a portable digital safety tester, can be used for testing;Safety level a test (CLASS I), safety level 2 test

(CLASS II), power strip grounding insulation and wiring, 220 v mains phase testing.

Can be widely used in household appliances and industrial equipment safety performance test.

Specification

Specifications	Range		Best Accuracy
Model			UT527
Insulation Resistance	Test Voltage	500V	√
	Class I PASS Value	1MΩ	±0.1MΩ
	Class II PASS Value	2MΩ	±0.1MΩ
	Cord PASS Value	2MΩ	±0.1MΩ
	Test Current	(R=500KΩ): >1mA	√
	Short-Circuit Current	<3mA	√
Ground Resistance	Class I PASS Value	0.2Ω	±0.03Ω
	Cord PASS Value	0.2Ω	±0.03Ω
	Test Current	>200mA ( R<2Ω )	√
	Measuring Voltage(DC)	5V	√
Cord Test	Correct Wiring	√Cord Fault	√
Cord Test	Open Circuit, Short Circuit, Reverse Polarity	X Cord Fault	√
Out with Testing	Test Voltage	AC220V	±10%
	Normal	Show"LN√,LE √,NE√”	√
	Off Ground	Show“LN√,LE X,NE X”	√
	Out Zero Line	Show“LN×,LE √,NE X	√
Features
Display Count			1999
Auto Power Off			√
Low Battery Indication			√
General Characteristic
Power	1.5V Batteries (LR14) x6
LCD Size	136mm X 47mm
Product Color	Red and Grey
Product Net Weight	970g
Product Size	210mm X 178mm X 90mm
Standard Accessories	Batteries,Test Cord, Alligator Clip
Standard Individual Packing	Gift Box, English Manual, Tool Box
Standard Quantity Per Carton	4 PCs
Standard Carton Measurement	510mm X 330mm X 330mm(0.056 CBM Per Standard Carton)
Standard Carton Gross Weight	11Kg
