Digital RCD (ELCB) Testers UNI-T UT581 AUTO RAMP function Leakage Circuit Breaker leakage protection switch tester
Digital RCD (ELCB) Testers UNI-T UT581 AUTO RAMP function Leakage Circuit Breaker  leakage protection switch tester


 Features


UT580 series Digital RCD (ELCB) Testers



1. AUTO RAMP function to test trip time and trip current;

2. 3 LED lamp for connectivity check;

3. Auto Data Hold function to display trip time for several seconds after each test;

4. Phase Switch Selection (0°and 180°) to test shortest triggering time;

5. Overload indication – “OL”;

6. Environmental: no battery is required. Powered directly from testing subject (A/C 220V/50Hz);

7. Fused protection and double insulation structure for extra safety;

8. ntelligent micro-processing controller to provide high-accuracy and reliability;

9Ergonomic design;

10Comply with IEC 61010-1 CAT III 300V; IEC 61557-1,5; IEC 61010-2-31.





Specification



Specifications Range Best Accuracy
Model   UT582 UT582
RCD Measurement Range Select Rated Operating Current Trip Time
X 1/2 10mA/20mA/30mA/100mA/
300mA/500mA		 1000mS √ √
X 1 10mA/20mA/30mA/100mA/300mA 1000mS √ √
500mA 300mS √ √
X 5 10mA/20mA/30mA 300mS √ √
250mA 250mA 40mS √
AUTO RAMP 10mA/20mA/30mA/100mA/
300mA/500mA		 300mS   √
Trip Current Accuracy   ±(2%+8) ±(2%+8)
Trip Time Accuracy   ±(0.6%+4) ±(0.6%+4)
Trip Time Resolution 1mS √ √
Operational Voltage(Freq.) 195V-253V(50Hz) √ √
Features
Display Count   1000 1000
Data Hold   √ √
Phase Switch  0°and 180° √ √
Connections Check Function Lamps Indication √ √
AUTO RAMP Function Test the trip time and trip current   √
Disconnect Buzzer   √ √
Over-Range Display OL √ √
Fused   √ √
Mis-Operation Buzzer   √ √
Power off Buzzer   √ √
Full Icon Display   √ √
General Characteristic
Power No Battery is required
LCD Size 71mm X 34mm
Product Color Red and Grey
Product Net Weight 400g
Product Size 160mm X 100mm X 71mm
Standard Accessories Test Lead,Carrying Bag
Standard Individual Packing Gift Box,English Manual
Standard Quantity Per Carton 20 PCs
Standard Carton Measurement 440mm X 430mm X 335mm (0.063CBM Per Export Carton)
Standard Carton Gross Weight 14Kg




Product Color Black
Product Net Weight 52g (Include Battery Not  Include Accessories)
Product  Size 120mmx32mmx23mm
Standard Accessories Battery (Device inside), Software, Strip (Not include Magnetic),Screws x 2 pcs
Standard Pack Gift Box, Manual
Standard Quantity Per Carton 72 Pcs
Standard Carton Size 410mmx375mmx245mm
Standard Carton Gross Weight 9KG
Optional Accessories* Strip (Include Magnetic)





Accessory



Test Lead,

Carrying Bag
