Help CenterUNI-T UT315 Digital Vibrometer With USB Interface, Vibrometer Range: 0.1~199.9m/s2(acceleration)
Related Products
-
Safety Testers UNI-T UT528 Handheld Battery Powered Tester MeterUS$ 120 - 170MOQ: 1 Piece -
Digital RCD (ELCB) Testers UNI-T UT581 AUTO RAMP Function Leakage Circuit Breaker Leakage Protection Switch TesterUS$ 50 - 75MOQ: 1 Piece
-
Digital RCD (ELCB) Testers UNI-T UT582 AUTO RAMP Function Leakage Circuit Breaker Leakage Protection Switch TesterUS$ 50 - 78MOQ: 1 Piece
-
Digital Inductance Capacitance Meters UNI-T UT603 Insulation Tester RESIOSTOR Meter 2uH-200H, 2nF- 600uFUS$ 15 - 30MOQ: 1 Piece
-
Digital Inductance Capacitance Meters UNI-T UT602 Insulation Tester RESIOSTOR Meter 20uH-2000H, 200pF-20mFUS$ 12 - 22MOQ: 1 Piece
Detailed
1 UT310 series handheld vibration meter is designed with acceleration sensor and digital measurement circuit. It’s mainly used in measuring the vibration of mechanical equipment, velocity, and acceleration. The measured data are compared with the national, international, corporate, machinery working standard to decide the condition (good, note or dangerous, etc.) of the machine(fan, pump, compressor, motor, etc.).
2 Can be widely used in mechanical manufacturing, electric power, petroleum chemical industry, metallurgy, aerospace and other fields. It’s the ideal measurement tool for purchasing inspection, operation monitoring and maintenance for the rotating machinery equipment.
| Specifications | Range | Best Accuracy | |
| Model | UT313 | UT315 | |
| Acceleration(Freq.) | 0.1~199.9m/s2 (10Hz ~ 10KHz) | ±(5%+2) | ±(5%+2) |
| Velocity(Freq.) | 0.01~19.99cm/s(10Hz ~ 1KHz) | ±(5%+2) | ±(5%+2) |
| Displacement(Freq.) | 0.001~1.999mm(10Hz ~ 500Hz) | ±(5%+2) | ±(5%+2) |
| Features | |||
| Display Count | 1999 | 1999 | |
| Auto Power Off | √ | √ | |
| Low Battery Indication | ≤7.0V | √ | √ |
| Data Hold | √ | √ | |
| MAX Mode | √ | √ | |
| Data Logging | 1999 | 1999 | |
| Data Recall | √ | √ | |
| USB Interface | √ | ||
| LCD Backlight | √ | √ | |
| General Characteristic | |||
| Power | 9V Alkaline Battery(6LF22) | ||
| LCD Size | 57mm X 37mm | ||
| Product Color | Red and Grey | ||
| Product Net Weight | 365g | ||
| Product Size | 166mm X 80mm X 30mm | ||
| Standard Accessories | UT313-Battery ,Magnet Pedestal,Long Probe,Short Probe,Connection Screw,Carrying Bag | ||
| UT315-Battery,USB Interface Cable,PC Software CD,Magnet Pedestal,Long Probe,Short Probe,Connection Screw,Carrying Bag | |||
| Standard Individual Packing | Gift Box, English Manual | ||
| Standard Quantity Per Carton | 40 PCs | ||
| Standard Carton Measurement | 530mm X 420mm X 365mm (0.081 CBM Per Standard Carton) | ||
| Standard Carton Gross Weight | 24 Kg |
||
Accessory
1. Battery, (not included because of the custome regulations)
2. USB Interface Cable,
3. PC Software CD,
4. Magnet Pedestal,
5. Long Probe,
6. Short Probe,
7. Connection Screw,
8. Carrying Bag
