Home > Instruments & Meters > Test Instrument > Test Machine > WF30 4mm Digital Color Meter Colorimeter Display Mode CIELAB CIELCH

WF30 4mm Digital Color Meter Colorimeter Display Mode CIELAB CIELCH

US$ 1,500 - 1,800 MOQ: 1 Piece

Key Specifications

Get Latest Price

Model Number:

WF30

Contact Supplier Request Quote Chat Now

Shenzhen Graigar Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Model Number WF30

Specifications

WF30 4mm Digital Color Meter Colorimeter Display Mode CIELAB CIELCH

Product Description

WF30 4mm Digital Color Meter Colorimeter Display Mode CIELAB CIELCH

Description:

WF30 colorimeter is a high precision, high stability, versatile colorimeter. WF30 has three measuring light sources (D50, D65 and F11), two color modes (CIE1976LAB, CIELCH), a color difference formula (ΔE * ab); two languages patterns (Simplified Chinese and English) and 3 measuring calibers to choose. WF30 colorimeter has a greater capacity of data storage space, you also can add mini-printers to do real-time printing measurement data. It can be used with standard "color analysis system" software.

WF30 colorimeter 4mm diameter version is a specially designed, especially for a small area, arc and other special surface type measuring cost-effective precision colorimeter. In a small device, small parts, arc exceptional color quality of face detection to bring great convenience for the user.

WF30 Precise Colorimeter
Model Number	WF30
Display mode	CIELAB,CIELCH
Color difference formula	ΔE *ab
Illumination Condition	CIE Recommendation:8/d
Light Source	The LED blue light excitation
Sensor	Photodiode array
Measuring Aperture	Φ4mm
Measuring Condition	Observer:CIE 10° Standard observer Light source: D65 D50 F11 (TL84) Contain light way:SCI SCE
Measuring Range	L:0-100
Repeated Accuracy	ΔE<0.05(take the deviation average after 30 times measuring the whiteboard)
Table Difference	ΔE <0.2
Measurement Time	0.5 second
Storage Capacity	100 standard samples and 20000 test sample
Battery Power supply	Li-ion battery, 5000 times Measurement
Lifetime of Bulb	5years more than 160 million measuring
Display screen	TFT true color 2.8inch@(16:9) Resolution ratio:400x240
Interface of External	USB2.0 (USB-B)-DATA communication with "color analysis system" software RS-232 (115200bps)- connected with micro printer
Working Temperature Range	0°C-40°C (32°F-104°F)
Storage Temperature Range	-20°C-50°C (-4°F-122°F)
Humidity Range	Relative humidity less than 85%,without condensation
Net Weight	700g
Dimension	199x68x90mm
Demension after package	400x240x340mm
Standard Accessory	3000mAH Li-ion battery/AC adapter/User manual/Warranty card
Optional Accessory	Flour measuring device/Liquid measuring device/Micro printer
