ESP Cable
EPDM Insulated Monel Armored 5KV ESP Cable
Application:
It is applied to power supply of ESP(Electric submersible pumps) system with the rating voltage less than 3kV or 6 kV, and has an outstanding capability of oil resistance and anti-corrosive resistance. The operating temperature of the conductor is 120°C,150°C,180°C,204°C,232°C,etc.
Standard: IEEE1018 API RP 11S6 GB/T16750 JB5332 ICEA
Configuration:
Conductor —— Solid or stranded tinned copper
Insulation —— EPDM/EPR
Sheath —— EPDM/EPR
Barrier —— Oil resistant or braid tape Layer(Separator)
Armor —— Galvanized Steel/stainless Steel/Monel interlocked tape armor
3kV Type
|
AWG No. |
Cross-section (Approximation) mm2 |
Conductor No./diameter mm |
Insulation Thickness mm |
Sheath Thickness mm |
Overall Dimensions mm×mm |
Reference weight kg/km |
1 |
3×42.4 |
1/7.35 |
1.9 |
1.0 |
16×45 |
3544 |
2 |
3×33.6 |
1/6.54 |
1.9 |
1.0 |
15×43 |
3116 |
4 |
3×21.1 |
1/5.19 |
1.9 |
1.0 |
14×38 |
2442 |
5 |
3×16.8 |
1/4.62 |
1.9 |
1.0 |
13×36 |
2211 |
6 |
3×13.3 |
1/4.12 |
1.9 |
1.0 |
12×34 |
1989 |
7 |
3×10.6 |
1/3.60 |
1.9 |
1.0 |
11×32 |
1767 |
6KV Type
|
AWG No. |
Cross-section (Approximation) mm2 |
Conductor No./diameter mm |
Insulation Thickness mm |
Sheath Thickness mm |
Overall Dimensions mm×mm |
Reference weight kg/km |
1 |
3×42.4 |
1/7.35 |
2.3 |
1.0 |
16×47 |
3850 |
2 |
3×33.6 |
1/6.54 |
2.3 |
1.0 |
15×45 |
3320 |
4 |
3×21.1 |
1/5.19 |
2.3 |
1.0 |
14×40 |
2730 |
5 |
3×16.8 |
1/4.62 |
2.3 |
1.0 |
13×38 |
2410 |
6 |
3×13.3 |
1/4.12 |
2.3 |
1.0 |
12×36 |
2100 |
7 |
3×10.6 |
1/3.60 |
2.3 |
1.0 |
11×34 |
1790 |
AWG sizes are approximate equivalent values. The actual cross-section is in mm².
Submersible oil pump power cable is used for submersible oil motor power supply. inculde round and flat, also could be buildup by all the power cable types together with different stainless steel pipe/tube sizes.
