Home > Instruments & Meters > Weighing & Measuring Apparatus > Measuring Device > TASI-675 Digital Coating Thickness Gauge Painting Width Detectable Substrate Material Ferrous Metal as Iron, Steel
TASI-675 Digital Coating Thickness Gauge Painting Width Detectable Substrate Material Ferrous Metal as Iron, Steel
US$ 180 - 260
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
TASI
Model Number:
TASI-675
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Film/Coating Thickness Gauge GM280 Paint Thickness MeterNegotiableMOQ: 1 Piece -
Film/Coating Thickness Gauge GM220 Paint Thickness MeterNegotiableMOQ: 1 Piece
-
Coating Thickness Gauge CM8801FN Thickness Meter Thickness TesterNegotiableMOQ: 1 Set
-
AR930 Ultrasonic Thickness Meter Film/Coating Thickness Gauge AR930NegotiableMOQ: 1 Set
-
KCT200 Paint Coating Thickness Gauge Thickness MeterUS$ 260 - 300MOQ: 1 Piece
Place of Origin
Guangdong, China
Brand Name
TASI
Model Number
TASI-675
Specifications
TASI-675 Digital Coating Thickness Gauge Painting Width Detectable Substrate Material Ferrous metal as iron, steelTASI-675 Digital Coating Thickness Gauge Painting Width Detectable Substrate Material Ferrous metal as iron, steel
GENERAL SPECIFICATIONS
Display: 3-½ digit liquid crystal display (LCD) with maximum reading of 1999.
Low Battery Indication: The “+ -” is displayed when the battery voltage drops below the operating level.
Measurement Rate: 1 second, nominal.
Operating Environment: 32°F to 122°F (0°C to 50°C) at < 75% R.H.
Storage Temperature: -4°F to 140°F (-20°C to 60°C), 0 to 80% R.H. with battery removed from meter.
Auto Power Off: 30 seconds without any operating.
Standby Consuming Current: Less than 15µA.
Battery: Standard 9V battery (NEDA 1604, IEC 6F22 006P).
Battery Life: 9 hours (continuity) typical (contain Back-lit).
Dimensions: 148mm (H) x 105mm(W) x 42mm(D).
Weight: Approx. 157g (including battery).
Detectable Substrate Material: Ferrous metal (iron, steel) .
ELECTRICAL
Thickness Range: 0 to 40.0mils (0 to 1000µm).
Display Resolution: 0.1mils/1µm.
Accuracy:
±4dgts on 0 to 7.8mils
±10dgts on 0 to 199µm
±(3%+4dgts) on 7.9mils to 40mils
±(3%+10dgts) on 200µm to 1000µm
Temperature Coefficient: ±0.1% of reading, whichever is greater, change in accuracy per °F/°C change in ambient operating temperature above 82.4°F/28°C or below 64.4°F/18°C.
Response Time: 1 second.
Edited by ZACK
