CM10FH Digital Coating Digital Coating Thickness Gauge Tester 0-10000um
- 200 Piece / Pieces per Month
- Shenzhen
- T/T D/P D/A Credit Card PayPal
You May Like
-
CM10N Coating Thickness Gauge Meter Tester 0-2000um
-
Digital coating thickness meter tester gauge CM10F
-
Coating Thickness Meter CM-8822 (F&NF),paint thickness meter,coating thickness gauge
-
Coating Thickness Meter CM-8828 /NF/FN type), paint thickness tester,auto paint thickness meter
-
MCT200 Paint Coating Thickness Gauge Tester
-
Film/Coating Thickness Gauge AR931,Ultrasonic thickness tester,Ultrasonic thickness gauge, thickness meters, thickness gauge
Product Details
| Brand Name | Graiger | Model Number | CM10FH |
Product Description
Specifications
CM10FH Digital Coating Digital Coating Thickness Gauge Tester 0-10000um
CM10FH Digital Coating Digital Coating Thickness Gauge Tester 0-10000um
CM10FH—Specification
Measuring Principle
Magnetic Method(Fe):
Measuring the thickness of
non-magnetic coatings on
steel, iron and other ferro-
magnetic metal substrates,
e.g.painting, varieties of
anti-corrosion coating, powder
spraying,plastic,rubber,
synthetic ,material,phosphate
coating, chromium, zinc,
aluminum,tin and cadmium,etc.
CM10FH—Specification
Measuring Principle:Magnetic Method
Measuring Range (um) :(0~10000)
Low Range Sensitivity (um) :10
Tolerance::±(2%H+10)
Testing Condition:Min. Curvature Radius(mm):10
Min. Measuring Surface(mm): 40
Min. Suibstrate Thickness(mm): 2
Display:Hight Contrast Segment Liquid Crystal Display(LED Backlight)
Statistics:N,MAX,MIN,MEAN,STD.DEV
Calibration:One-point Calibration,Two-point Calibration
Auto Power-off:3Auto off after 3 minutes of inactivity
Power:Two 1.5V AA batteries,low-voltage indication function
Weight:200g
Size:149mm×73mm×32mm (H×W×D)
