DT-2234B Digital Photoelectric Tachometer

Name: DT-2234B Digital Photoelectric Tachometer
Brand: Graigar
SKU: 130802483
Availability: InStock

Shenzhen Graigar Technology Co., Ltd.

US$ 85 - 95 MOQ: 1 Piece

Key Specifications

Brand Name:

Graigar

Model Number:

DT-2234B

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Brand Name Graigar

Model Number DT-2234B

Specifications

DT-2234B Digital Photoelectric tachometer

DT-2234B Digital Photoelectric tachometer

LUTRON DT-2234B Photo Tachometer

Items	PHOTO TACHOMETER
Model	DT-2234B
Range	5 to 99,999 RPM
Resolution	RPM	0.1 RPM	< 1,000 RPM
		1 RPM	1,000 RPM
Display	5 digits, 10 mm ( 0.4" ) LCD.
Accuracy	+/- ( 0.05 % + 1 digit ).
Sampling Time	1 second ( 60 RPM ).
Time base	Quartz crystal .
Photo Tach. detecting distance	50 to 150 mm/2 to 6 inch. * Typical max. 300 mm/12 inch depending upon ambient light.
Circuit	Exclusive one-chip of microcomputer LSI circuit.
Battery	1.5 V AA (UM-3) battery x 4 PCs.
Operating temp.	0 to 50C ( 32 to 122F ).
Memory	Last value, Max. value, Min. value.
Size	190 x 72 x 37 mm (7.5 x 2.8 x 1.5 inch).
Weight	250g (0.55 LB)/including battery.
Accessories	Carrying case .............................. 1 PC Reflecting tape marks (600 mm) ................................................... 1 PC Operation manual ........................ 1 PC
