Specifications
RM-1500 Digital Tachometer
RM-1500 Digital Tachometer
5 Digits LCD Display
Light Reflex Measurement
Range 10.00 to 99,999 RPM
Measuring Distance 50 to 300mm
Event counter with elapsed time
RM-1502 optional Contact Adaptor
Max / Min / Hold : True Average
Auto Range RPM
II.Specification:
Speed ( Optical )
|
Range |
Resolution |
Accuracy |
RPM |
10.00-99999 |
0.01/0.1/1 |
0.04%+-2dgtst |
rps (HZ) |
0.2-2000 |
0.001/0.01/01 |
0.04%+-2dgtst |
Speed ( Contact )
|
Range |
Resolution |
Accuracy |
RPM |
10.00 - 29999 |
0.01/0.1/1 |
0.04%+-2dgtst |
m/min |
1.000 - 2999.9 |
0.001/0.01/0.1 |
0.04%+-2dgtst |
ft/min |
4.00 - 10000 |
0.01/0.1/1 |
0.04%+-2dgtst |
yard/min |
2.00 - 3000 |
0.01/0.1/1 |
0.04%+-2dgtst |
rps (Hz) |
0.2 - 500 |
0.001/0.01/0.1 |
0.04%+-2dgtst |
Event Counter
Range |
Max. Input Frequency |
0 -99999 |
10KHz. with 5% duty cycle |
NEW PROVA RM-1500 Digital Tachometer RM1500
General Specification
External TTL Input |
High > 4.5V (RM-1501) |
Display |
5 digits 99999 counts |
Sampling Rate |
0.7 second ( > 60 rpm) |
Measuring Distance |
50 to 300mm |
Time Base |
4.0 MHz Quartz Crystal |
Range Selection |
Automatic |
Battery |
Four 1.5V batteries (AA, UM-3) |
Power Consumption |
1.5mA(Idle) |
Auto-Power-Off |
30 minutes. |
Operating Temp. |
0 C ~ 50 C ( 32 F ~122 F ) |
Size |
72 mm x 63mm x 36mm (6.8" x 2.5" x 1.5") |
Weight |
190g (6.7 oz.) (including battery) |
Accessories |
Carrying Case x 1 ,Reflective tape x 1 , Instruction Manual x 1 |
