Coating Thickness Gauges UNI-T UT342 Film Thickness Tester Iron Aluminum Matrix Measure 9999 Display Count
US$ 90 - 110
MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
UNI-T
Model Number:
UT342
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
NEW LUTRON Measuring Instrument VT-8204 Vibration MeterUS$ 850 - 950MOQ: 1 Piece -
Free Shipping Velocity:0.5-199.9mm/s,acceleration:0.5-199.9m/s^2, Vibration Meter VB-8202US$ 600 - 700MOQ: 1 Piece
-
GM63B Digital Vibrometer, Vibrometer Tester,Vibration Meter 0.1-199.m/S2 Peak(rms*v2)US$ 210 - 300MOQ: 1 Piece
-
Vibration Meter VM-6310,Vibration Tester,digital Vibration GaugeNegotiableMOQ: 1 Piece
-
Vibration Meter VM-6360,Vibration Tester,digital Vibration GaugeNegotiableMOQ: 1 Piece
Brand Name
UNI-T
Model Number
UT342
Coating Thickness Gauges UNI-T UT342 Film thickness Tester Iron Aluminum Matrix Measure 9999 Display Count
FEATURES
UT340 Series coating thickness gauge is a stable, safe and reliable, the appearance of new measuring instruments, it can quickly and without injury, Chi precision measurement of non-magnetic cover layer thickness of the magnetic and non-magnetic conductor on the substrate.
It can be widely used in manufacturing, metal processing, chemical industry, commodity inspection and testing fields.
SPECIFICATION
| Specifications | Range | Best Accuracy | |
| Model | UT341 | UT342 | |
| Iron Matrix Measure | 0μm-55μm | ±3dgt | ±3dgt |
| 56μm-1000μm | ±(3.0%+1dgt) | ±(3.0%+1dgt) | |
| Aluminum Matrix Measμre | 0μm-55μm | ±3dgt | |
| 56μm-1000μm | ±(3.0%+1dgt) | ||
| Resolution | √ | √ | |
| Features | |||
| Display Count | 9999 | 9999 | |
| Auto Power Off | √ | √ | |
| Low Battery Indication | √ | √ | |
| Data Hold | √ | √ | |
| MAX/MIN | √ | √ | |
| Data Logging | 2000 | 2000 | |
| LCD Backlight | √ | √ | |
| Measurement Mode | Continuous or Single Measurement | √ | √ |
| Key Mis-press Buzzer | √ | √ | |
| General Characteristic | |||
| Power | 9V Alkaline Battery(6LF22) | ||
| LCD Size | 22mm X 22mm | ||
| Product Color | Red and Grey | ||
| Product Net Weight | 144.2g | ||
| Product Size | 153mm X 110mm X 40mm | ||
| Standard Accessories | UT341-Battery,Standard Membrane Slice, Iron Matrix Slice, Carrying Bag | ||
| UT342-Battery,Standard Membrane Slice, Iron Matrix Slice, Aluminum Matrix Slice,Carrying Bag | |||
| Standard Individual Packing | Gift Box, English Manual | ||
| Standard Quantity Per Carton | 40 PCs | ||
| Standard Carton Measurement | 530mm X 485mm X 320mm (0.082 CBM Per Standard Carton) | ||
| Standard Carton Gross Weight | 9.5 Kg | ||
Accessory
1. Battery, (not included because of the custom regulations)
2. Standard Membrane Slice,
3. Iron Matrix Slice,
4. Aluminum Matrix Slice,
5. Carrying Bag
