Digital Torque Gauge ANL-50 Torque Meter
US$ 860 - 950
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Graigar
Model Number:
ANL-50
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
CS-10 TYPE LOAD CELL Could be Used to Make Pyrostat , Specially for Steel-coating Balance.US$ 50 - 500MOQ: 1 Piece -
CS-13 TYPE LOAD CELL Especially Good for Electronic Belt Scale.hopper Scale. Platform Scale and Ground Weigher.US$ 50 - 500MOQ: 1 Piece
-
CS-12 TYPE LOAD CELL Extensively Applied in the Meterage Measurement Such as Mine , Iron and Steel.US$ 90 - 500MOQ: 1 Piece
-
CS-11 TYPE LOAD CELL Can be Directly Fitted at Coincidence to the Tracks to Weigh the Materials.US$ 50 - 500MOQ: 1 Piece
-
CS-14 TYPE LOAD CELL Apply to Various Force Measurement by Platform Balance, Belt Balance, Hopper ScaleUS$ 50 - 500MOQ: 1 Piece
Place of Origin
Guangdong, China
Brand Name
Graigar
Model Number
ANL-50
Digital torque gauge ANL-50 torque meter
Features:
1. Easy to carry
2. High accuracy
3. Can connect to PC
4. One year warranty
5. Complete functions
Digital torque meter is an intelligent multi-functional measuring instrument which is designed for testing various kinds of torque. It main used in testing and calibration various kinds of electric pneumatic screwdriver set, the torque of torque wrench, all kinds of products refer to testing of screw down force, parts torsion destructive testing etc. With features of simple operation, high precision, easy to carry, complete functions etc. It's widely used in various kinds of electric, light industry, machinery manufacturing, research institutions, etc.
| Type | With printer | ANL-50P | ANL-100P | ANL-200P | ANL-300P | ANL-500P |
| No printer | ANL-50 | ANL-100 | ANL-200 | ANL-300 | ANL-500 | |
| Measuring range / Division value | N·m | 50.000/0.001 | 100.00/0.01 | 200.00/0.01 | 300.00/0.01 | 500.00/0.01 |
| Kg·cm | 510.52/0.01 | 1021.0/0.1 | 2042.0/0.1 | 3063.1/0.1 | 5105.2/0.1 | |
| Ib·in | 443.11/0.01 | 886.2/0.1 | 1772.4/0.1 | 2658.6/0.1 | 4431.1/0.1 | |
| Precision | ±0.1% | |||||
| Peak Value Sampling Frequency | 2000HZ | |||||
| Power | 8.4V 1.2VX7Ni-MH Battery group | |||||
| Charging Time | 4~6 Hours | |||||
| Continuous using time of battery | About 10 Hours | |||||
| Battery life | ≥300 times | |||||
| Size | With printer: Host display part 230 mm x 95 mm x 180 mm | |||||
| Measuring device part 480 mm x 190 mm x 180 mm | ||||||
| No printer: Host display part 230 mm x 70 mm x 125 mm | ||||||
| Measuring device part 480 mm x 190 mm x 180 mm | ||||||
| Net Weight | With printer: 36 KG No printer: 34 KG | |||||
| Power adapter | Input: Optional, Output: DC 10 V 300 mA | |||||
