Rotary Digital Viscometer Viscosity Tester NDJ-5S 1~100000 mPa.s
NDJ-5S is a Digital rotary viscometer which has been upgraded. This viscometer adopts advanced mechanical design technology, manufacturing process and micro computer control technology, make the data acquisition correct and the display adopts LCD with blue backlight and high brightness, make the displayed data clear.
NDJ-5S Digital rotary viscometer is used for determining the liquid viscose capacity and the absolute viscosity. Comparing with other similar products, this instrument has the following features:
High measuring accuracy;
Stable in measured display;
Easy operation and read-out;
Excellent in Anti- interference.
NDJ-5S has been widely used to determine and measure the liquid viscosity in many applications such as grease, painting, pharmacy and adhesives.
2. Main technical data
1) Measurement range: 1~100000 mPa.s
2) Rotor types: 1#, 2#, 3# and 4# rotors; (You can determine viscosity as low as 0.1mPa.s with 0# rotor.)
3) Rotor velocity: 6 rpm, 12 rpm, 30 rpm, and 60 rpm(automatic)
4) Accuracy: ±1.0% of range
5) Power supply: Electronic,100-240V/50-60Hz
6) Ambient temperature: 5°C~ 35°C; Relative humidity: ≤80%
Packing List
No. |
Name |
Quantity |
Standard configuration |
Optional configuration |
1 |
NDJ-5S Digital Rotary Viscometer |
1 Qt. |
√ |
|
2 |
Rotors, 1#, 2#, 3# and 4# |
1 Qt of each |
√ |
|
3 |
Power adapter |
1 Set |
√ |
|
4 |
Protection bracket |
1 Qt. |
√ |
|
5 |
Base |
1 Qt. |
√ |
|
6 |
Lifting assembly |
1 Set |
√ |
|
7 |
Operation manual |
1 Qt. |
√ |
|
8 |
License |
1 Qt. |
√ |
|
9 |
Quality certificate |
1 Qt. |
√ |
|
10 |
0# rotor |
1Qt. |
|
√ |
