Specifications
1.HBZ-3000A Automatic Brinell Hardness Tester2.Measuring range: 32-650HBW
3.Power supply:380V AC or 220V AC, 50 or 60Hz.
HBZ-3000A Automatic Brinell Hardness Tester
Feature & Use:
Automatic testing process, high precision optical grating measuring system, automatic digital display, no human operating & reading errors
The attached printer can automatically print out the hardness testing result
Precision conforms to GB/T 231.2, ISO 6506-2 and ASTM E10
It can be used to determine the Brinell hardness of unquenched steel, cast iron, non-ferrous metals and soft bearing alloys, etc. It is especially suitable for on-line & on-spot determining of the hardness of test pieces in large batches.
Specifications:
Measuring range: 32-650HBW
Test force: 7355.3, 9807, 29421N (750, 1000, 3000kgf)
Max. height of test piece: 450mm
Depth of throat: 170mm
Power supply: 380V AC, 50 or 60Hz
Dimensions: main machine --- 920 x 720 x 1760mm (36.5x28.5x70 inch)
control box --- 510 x 500 x 1450mm (20x19.5x57 inch)
Weight: main machine --- approx. 900kg / 1980lb
control box --- approx. 40kg / 88lb
Standard accessories:
Flat anvil: 1 pc.
V-notch anvil: 1 pc.
Tungsten carbide ball penetrator: Φ5, Φ10mm, 1 pc. Each
Brinell standardized block: 2 pcs.
20X Readout microscope: 1 pc.
