Specifications
1.HBV-30A Brinell Vickers Hardness Tester2.Measuring range:4-650HBW, 10-3000HV
3.Max. height of test piece: 130mm
HBV-30A Brinell Vickers Hardness Tester
Application & Feature:
It's suitable to determine the Vickers hardness of steel, non-ferrous metals, ceramics, treated layers of metal surface, and the hardness grads of carburized, nitrided and hardened layers of metals.
It is also suitable to determine the Vickers hardness of micro and super thin parts and the Brinell hardness of soft metals and small parts.
1. Automatic testing process, no human operating error
2. Precision conforms to GB/T 4340.2, GB/T 231.2, ISO6506-2, ISO6507-2, ASTM E92 and ASTM E10
Specifications:
1.Measuring range: 4-650HBW, 10-3000HV
2.Test force: 9.807, 24.52, 49.03, 98.07, 196.1, 294.2N (1, 2.5, 5, 10, 20, 30kgf)
3.Max. height of test piece: 130mm
4.Depth of throat: 100mm
5.Magnifications of the measuring system: 500X, 125X
6.Min. scale value of the optical micrometer: 0.25um
7.Power supply: 220 AC or 110V AC, 50 or 60Hz
8.Dimensions: 438 x 382 x 708mm
9.Weight: approx. 88kg
Standard accessories:
Coordinate anvil: 1 pc.
Large flat anvil: 1 pc.
Small flat anvil: 1 pc.
V-notch anvil: 1 pc.
Tungsten carbide ball penetrator: Φ1, Φ2mm, 1 pc. each
Diamond pyramid penetrator: 1 pc.
Brinell standardized block: 2 pcs.
Vickers standardized block: 2 pcs.
Electronic calculator: 1 pc.
