Portable Leeb Hardness Tester/Meter/Gauge MH180 With Large Storge Capacity

Name: Portable Leeb Hardness Tester/Meter/Gauge MH180 With Large Storge Capacity
Brand: Graigar
SKU: 130791259
Availability: InStock

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

Graigar

Model Number:

MH180

Shenzhen Graigar Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

SHENZHEN

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name Graigar

Model Number MH180

Portable Leeb Hardness Tester/Meter/Gauge MH180 with large storge capacity

PRODUCT INFORMATION

Model MH180 hardness tester is develop model of HL200, its in durable metal case, hardness scales are convertable among

hardness units: HRB, HRC, HV, HB, HS, HL ;attachable thermal mini-printer, fast on-site print;software data and upperlower limits

setting and sound alarm; large storage capacity.

SPECIFICATIONS

Measuring Range	HLD(170-960)
Impact Derections	up,down,horizontal,slanting up,slanting down
Measuring materials	steel and cast steel, cold work tool steel, stainless steel,grey cast iron, nodular cast iron,cast aluminium allorys,brass(coppper-zinc alloys), Bronze(copper-alluminium alloys/copper-tin alloys),wrought copper alloys
Hardness scales	Leeb, Brinell, Rockwell A,B,C, Vicker, Shore
Display	128*64 digital matrix LCD
Memory	500 group(32 every group)
Work voltage	3V( 2 AA alkaline battaries)
Interface port	RS232
Dimensions	132mm76mm33mm
Weight	345g
Continuous working period	100 hours (with backlight off)

ACCURACY AND REPEATABILITY OF DISPLAYED VALUE

No.	Type of impact device	Hardness value of Leeb standard hardness block	Erro of displyed value	Reapeatability of displayed value
1	D	760±30HLD 530±40HLD	±6 HLD ±10 HLD	6HLD 10HLD
2	DC	760±30HLD 530±40HLD	±6 HLDC ±10 HLDC	6HLD 10HLD
3	DL	878±30HLD 736±40HLD	±12 HLDL	12HLDL
4	D+15	766±30HLD 544±40HLD	±12 HLD+15	12HLD+15
5	G	590±40HLD 500±40HLD	±12 HLG	12HLG
6	E	725±30HLD 508±40HLD	±12 HLE	12HLE
7	C	822±30HLD 590±40HLD	±12 HLC	12HLC

STANDARD DELIVERIES

OPTIONAL DELIVERIES

No	Items	Quantity
1	Other types of cleaning brush	1
2	Other types of impact devices	6
3	Tool for install imapct ball	1
4	Other types of support ring	1
5	Other types of imapct ball/body	1
6	Mini-printer	1
