Fused Silica Windows fast delivery
USD $1 - $50
/ Piece
10 Pieces(Min.Order)
- 10000 Piece / Pieces per Month
- Qingdao
You May Like
Product Details
| Place of Origin | Shandong, China | Brand Name | Sdhengjing | |
| Model Number | Customization |
Product Description
Description:
| Material | UV grade fused silica |
| Dimension Tolerance | +0.0/-0.2mm |
| Thickness Tolerance | ±0.2mm |
| Clear Aperture | >90% |
| Parallelism | Standard: 1 arc minute High Precision: 10 arc seconds |
| Surface Quality | Standard: 60/40 High Precision: 20/10 |
| Wavefront Distortion | Standard: λ@633nm per 25mm High Precision: λ/10@633nm per 25mm |
| Chamfer | Protected <0.5mmx45deg |
| Coating | Uncoated, available |
Standard | High Precision | ||||||
Part No. | ø(mm) | T(mm) | Part No. | ø(mm) | T(mm) | ||
WIN2010 | 10.0 | 3.0 | WIN2110 | 10.0 | 6.0 | ||
WIN2012 | 12.7 | 3.0 | WIN2112 | 12.7 | 6.0 | ||
WIN2015 | 15.0 | 3.0 | WIN2115 | 15.0 | 6.0 | ||
WIN2020 | 20.0 | 3.0 | WIN2120 | 20.0 | 6.0 | ||
WIN2025 | 25.4 | 3.0 | WIN2125 | 25.4 | 6.35 | ||
WIN2030 | 30.0 | 3.0 | WIN2130 | 30.0 | 6.35 | ||
WIN2050 | 50.8 | 6.35 | WIN2150 | 50.8 | 10.0 | ||
