Pin Type Insulators For High Voltage

Pin Type Insulators For High Voltage photo-1
US$ 0.5 - 1.76 MOQ: 3000 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Jiangxi, China
Brand Name:
TSBXJ
Model Number:
55 series
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen/Shanghai/Ningbo
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Jiangxi, China
Brand Name TSBXJ
Model Number 55 series
Type Insulator
Material Porcelain
Application High Voltage
Rated Voltage v
Tensile Strength n


Pin Type Porcelain Insualtor For High Voltage



Class ANSI

55-1

55-2

55-3

55-4

55-5

Creepage Distance

102

127

178

229

305

Dry arcing distance

57

86

114

127

159

Cantilever strength (KN)

13

11

11

13

13

Low frequency dry flashover voltage

35

45

56

65

80

Low frequency wet flashover voltage

20

25

30

35

45

Critical impulse flashover pos(kv)

50

70

90

105

130

Critical impulse flashover Neg(kv)

70

85

110

130

150

Power-frequency puncture voltage(kv)

50

70

90

95

115

Test voltage to ground (kv)

5

5

10

10

15

Maximum RIV at 1000HZ(uv)

50

50

50

50

100

Net weight each approx(kg)

0.5

0.65

1

1.55

2.75

Number in standard package

60

40

30

16

12
