Pin Porcelain Insulator
US$ 1.01 - 2.08
MOQ: 1500 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Jiangxi, China
Brand Name:
TSBXJ
Model Number:
p-11-y
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen shanghai ningbo
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
11kv Pin Porcelain InsulatorUS$ 1 - 2.1MOQ: 1500 Pieces -
Hot Sale 20kv Pin InsulatorUS$ 1.2 - 3.5MOQ: 3600 Pieces
-
Low Price Pin Type Porcelain Insulator for High VoltageUS$ 0.32 - 0.35MOQ: 6000 Pieces
-
Low Voltage N80-- Pin Porcelain InsulatorsUS$ 0.3 - 0.5MOQ: 1000 Pieces
-
Russia Market Pin Type Insulator for 20kv Lines,low VoltageUS$ 1 - 5MOQ: 3600 Pieces
Place of Origin
Jiangxi, China
Brand Name
TSBXJ
Model Number
p-11-y
Performance characterustucsof the ceramics insulator as follows:
| Type | P-11-Y | P-15-Y | P-20-Y | P-33-Y | |
| Main Dimensions mm |
H | 133 | 137 | 195 | 244 |
| h | 48 | 48 | 52.63 | 52.63 | |
| D | 140 | 152 | 230 | 279 | |
| d | 18.29 | 18.29 | 27.78 | 27.78 | |
| R1 | 13 | 13 | 19 | 19 | |
| R2 | 9.5 | 12.7 | 14.3 | 13 | |
| Nominal Voltage/kV | 11 | 15 | 22 | 33 | |
| Creepage Distance/mm | 240 | 298 | 432 | 630 | |
| Weight | 1.8 | 11.5 | |||
