MSO2302A digital oscilloscope 300MHz 2+16channels

Specifications

MSO2302A digital oscilloscope 300MHz 2+16channels

product feature:

The oledata.mso/DS2000A series digital oscilloscope is 70 MHZ to 300 MHZ

bandwidth, sampling rate is as high as 2 gsa/s, at the same time be both deep

storage depth and high reflection of capture rate high performance general

purpose digital oscilloscope. MSO2000A have 2 + 16 channels, is for the

embedded design and testing of applications in the field of high performance

mixed signal oscilloscope. The oledata.mso/DS2000A series adopted many

of today's advanced technology and process, the overall performance reached

the international advanced level, is the most widely for digital oscilloscope

market including communications, semiconductors, computers, aerospace

defense, instruments and meters, industrial electronics, consumer electronics,

automotive electronics, on-site maintenance, r&d/education and so on in the

field of general design/debug/test requirements and design of the oscilloscope

1.Bandwidth of 300 MHZ, with 50 Ω input selection

2.Two analog channel, 16 digital channel (the oledata.mso)

3.Wide range, low noise, vertical sensitivity range: 500 uv/div ~ 10 V/div

4.Real-time sampling rate is as high as 2 g Sa gsa/s/s digital channel 1 (the oledata.mso)

5.Standard storage depth of 14 MPTS, matching up to 56 MPTS standard digital channels

for 14 MPTS, matching up to 28 MPTS

6.Waveform capture rate was 50000 per second waveform

7.With as many as 65000 frames of hardware real-time waveform uninterrupted recording and waveform analysis

8.The built-in dual channel, 25 MHz signal source (the oledata.mso/DS2000A - S)

9.Rich trigger and bus decoding function (parallel, RS232, I2C, SPI, CAN)

10.Rich interface: USB Host&Device, LAN (LXI), AUX, USB - GPIB (optional)

11.A novel sophisticated industrial design, convenient operation

12.8 "WVGA (800 x 480), a level 256 waveform grayscale display
