High Pressure Breathing Air Compressor MCH6/EM

High Pressure Breathing Air Compressor MCH6/EM thumbnail-1
High Pressure Breathing Air Compressor MCH6/EM photo-1
US$ 1 - 2,500 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Shanghai, China
Brand Name:
AS
Model Number:
AS-MCH6/ET
Contact Supplier Request Quote Chat Now
Ayon Safety (Shanghai) Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shanghai, China
Brand Name AS
Model Number AS-MCH6/ET



High Pressure Air Compressor



High pressure breathing air compressor MCH6/EM

Brief Introduction:

MCH6 series breathing air compressor is the most portable compressor in the whole industrial.

There are 3 kinds of compressors meeting different customers’ requirements, which are “MCH6/ET STANDARD (Three-phase)”, “MCH6/EM STANDARD (Single-phase)” and “MCH6/SH STANDARD (Petrol engine)”.

We have big advantage of lightest weight and smallest volume. The petrol engine of MCH 6 series only 37KG, can easily put in the trunk of the car, carry to use the site, it can be used in firefighting, scuba diving, shooting, emergency rescue, chemical, oil field and other fields and are convenient to move, easy operation, the high pressure air are meet EN 12021 standard.



Characteristics & Features:



MCH 6-100 L series breathing air compressor, equipped with automatic stop function, can realize the inflatable process unattended, to provide you with a higher safety protection.

­MCH 6-100 L series breathing air compressor, equipped with G5/8 & M22x1. 5 double thread gasification valve, can free butt joint the mainstream and non-mainstream cylinders interface.



Product structure:



Optional petrol engine, three-phase, single-phase electric driven motor, V belt drive

Four cylinder level 4 high-pressure compressor

Stainless steel cooler between every level.

Installed in the 400 bar high pressure on the compressor pressure gauge

1.2 meters high pressure air tube, joints according to the needs of you

Stainless steel fan cover

Two oil-water separator, two drain valve (optional automatic decontamination)

Activated carbon molecular sieve filtration system

To set pressure automatic stop, prevent the relief valve frequent rev. Jump, ensure safety and security



Specification:





Filling time cylinder:

6.8L 0-300bar/25.5min

12L 0-200bar/30min

Charging rate:

80L/min  4.8m3/H   2.8CFM

Working pressure:

For diving: 225 Bar / 3300 Psi

For firefighting: 300 Bar / 4300 Psi

Full load Amp:

16A (230V-50/60Hz)

Driven by:

Single-phase electric motor

Power:

2,2 Kw

Dimensions:

height 35cm, width 65cm, depth 39cm

Dry weight:

39.5 Kg / 87 lbs

Noise pressure:

81,7 dB

Number of stages and cylinders:

4

Lubricating oil capacity:

300 cc (0,3 L) / 10 FL. OZ.

Lubricant:

CE 750

Oil/moisture separator:

After last stage

Filtration:

Filter cartridge activated carbon and molecular sieve

Suction filter:

2 micron paper - 25 micron polyester

Breathing air:

EN 12021 CGA E











Our certifications



High pressure breathing air compressor MCH6/EM
