High Pressure Air Compressor
200 bar / 300 bar High pressure breathing air compressor SCBA air compressor MCH6/ET
Brief Introduction:
MCH6 series breathing air compressor is the most portable compressor in the whole industrial.
There are 3 kinds of compressors meeting different customers’ requirements, which are “MCH6/ET STANDARD (Three-phase)”, “MCH6/EM STANDARD (Single-phase)” and “MCH6/SH STANDARD (Petrol engine)”.
We have big advantage of lightest weight and smallest volume. The petrol engine of MCH 6 series only 37KG, can easily put in the trunk of the car, carry to use the site, it can be used in firefighting, scuba diving, shooting, emergency rescue, chemical, oil field and other fields and are convenient to move, easy operation, the high pressure air are meet EN 12021 standard.
Characteristics & Features:
MCH 6-100 L series breathing air compressor, equipped with automatic stop function, can realize the inflatable process unattended, to provide you with a higher safety protection.
MCH 6-100 L series breathing air compressor, equipped with G5/8 & M22x1. 5 double thread gasification valve, can free butt joint the mainstream and non-mainstream cylinders interface.
Product structure:
Optional petrol engine, three-phase, single-phase electric driven motor, V belt drive
Four cylinder level 4 high-pressure compressor
Stainless steel cooler between every level.
Installed in the 400 bar high pressure on the compressor pressure gauge
1.2 meters high pressure air tube, joints according to the needs of you
Stainless steel fan cover
Two oil-water separator, two drain valve (optional automatic decontamination)
Activated carbon molecular sieve filtration system
To set pressure automatic stop, prevent the relief valve frequent rev. Jump, ensure safety and security
Specification:
Filling time cylinder: |
6.8L 0-300bar/20.4min 12L 0-200bar/24min |
Charging rate: |
100L/min 6m3/H 3.5CFM |
Working pressure: |
For diving: 225 Bar / 3300 Psi For firefighting: 300 Bar / 4300 Psi |
Full load Amp: |
16A (230V-50Hz/230V-60Hz/400V-50Hz/440V-60Hz) |
Driven by: |
Three-phase electric motor |
Power: |
3Kw |
Dimensions: |
height 35cm, width 65cm, depth 39cm |
Dry weight: |
39 Kg / 85 lbs |
Noise pressure: |
83 dB |
Number of stages and cylinders: |
4 |
Lubricating oil capacity: |
300 cc (0,3 L) / 10 FL. OZ. |
Lubricant: |
CE 750 |
Oil/moisture separator: |
After last stage |
Filtration: |
Filter cartridge activated carbon and molecular sieve |
Suction filter: |
2 micron paper - 25 micron polyester |
Breathing air: |
EN 12021 CGA E |
